TLC5917 or TCA6507 Led drivers msp430f2272 C implementation

//******************************************************************************
//
//   Description: The MSP430G2553 acts as the SPI master to three
//	 TLC5927/TLC5926 LED drivers sinking current from 16 channels each.
//	 The drivers sink current from 16 RGB LEDs with each driver sinking
//	 current from a particular color node (Red, Green, or Blue).  The SPI
//	 SCLK is sourced by the SMCLK = DCO ~16MHZ.  The SPI module used by the
//	 SPI master is USCI_B0 in SPI mode.
//
//	 Timer1_A3 is used to provide PWM outputs in order to dim LEDS.  This is
//	 done through the OE' pin on the drivers.  The timer is also sourced by
//	 the SMCLK.
//
//	 This file is an edited version of D. Dang's source code, titled:
//   MSP430G2xx3 Demo - USCI_A0, SPI 3-Wire Master Incremented Data.
//
//                    MSP430G2553
//                 -----------------
//          LED <-|P1.0             |
//                |                 |
//          TXD <-|P1.1          RST|-> Reset Button
//                |                 |
//          RXD <-|P1.2         P1.7|-> SIMO (UCB0SIMO)
//                |                 |
//    Button S2 <-|P1.3				|
//				  |
//  		 LE <-|P1.4         P1.6|<- SOMI (UCB0SOMI)
//                |                 |
//  		OE' <-|P2.1         P1.5|-> SCLK (UCB0CLK)
//
//
//	 Roberto Mancera Jr
//   Texas Instruments Inc.
//   June 2011
//   Built with CCS Version 4.2.3
//******************************************************************************
#include "msp430g2553.h"
#include "uart.h"

#define SCLK		BIT5
#define LE 			BIT4
#define OE 			BIT1

void initialize_clk();
void initialize_SPI();
void global_blink(char duty, char period, unsigned int seq_R, unsigned int seq_G,
	unsigned int seq_B, char blink_period);
void latch_out(unsigned int seq_R, unsigned int seq_G, unsigned int seq_B);
void pwm_config( unsigned char half_duty, unsigned char half_period);
void special_conf(unsigned int config_code_R, unsigned int config_code_G,
	unsigned int config_code_B);
unsigned int special_err();
void switch_mode(unsigned char mode);
void default_prog();
void prog_1();
void prog_2();

unsigned char b_state;						// Stores button press state

void main()
{
  initialize_clk();							// Set up basic clk module
  WDTCTL = WDTPW + WDTHOLD;                 // Stop watchdog timer
  P1OUT = 0x00;
  P2OUT = BIT1;								// Initialize OE' (LEDs off)
  P1DIR = BIT0 + BIT4;

  initialize_SPI();

  P1IE |= BIT3;								// Initialize P1.3(button) interrupt
  __bis_SR_register(GIE);

  __delay_cycles(75);                 		// Wait for LED driver to initialize

  default_prog();
}

/*
 * 	Function: PORT1_ISR
 *  Description: Interupts the processor to change the
 * 		the button press state. This changes the current
 * 		LED sequence program.
 *  Parameters: none
 *  Return: none
 */
#pragma vector=PORT1_VECTOR
__interrupt void PORT1_ISR(void)
{

}

unsigned char send_receive_pc(unsigned char send)
{
  unsigned char receive;

  TimerA_UART_init();
  receive = TimerA_UART_rx_tx(send);
  TimerA_UART_shutdown();

  return receive;
}

void initialize_clk()
{
  if (CALBC1_16MHZ == 0xFF || CALDCO_16MHZ == 0XFF) // Calibrate DCO at 16 MHz
  	while(1);										// 		DCO=MCLK=SMCLK
  BCSCTL1 = CALBC1_16MHZ;
  BCSCTL2 = DIVS_1;
  DCOCTL = CALDCO_16MHZ;
}

/*
 *  Function: initialize_SPI
 *  Description: Initializes module USCI_B0 in SPI 3 wire mode.  This
 * 		module is to be used to communicate with the TLC5927 LED drivers.
 * 		the module is set up to output to the SDI by send the LSB of a 16
 * 		bit word first.
 *  Parameters: none
 *  Return: none
 */
 void initialize_SPI()
 {
  P1SEL = BIT5 + BIT6 + BIT7;				// setup SCLK = p1.5, SOMI = p1.6,
  P1SEL2 = BIT5 + BIT6 + BIT7;				//		SIMO = P1.7
  UCB0CTL0 |= UCMST + UCSYNC;  				// 3-pin, 8-bit SPI master
  UCB0CTL1 |= UCSSEL_2;                     // SMCLK
  UCB0BR0 |= 0x01;                          // SMCLK/1
  UCB0BR1 = 0;
  UCB0CTL1 &= ~UCSWRST;                     // **Initialize USCI state machine**
 }

 /*
 *  Function: global_blink
 *  Description: Execute rx/tx communication via SPI to force LED drivers
 * 		to blink particular channels.  The channels are on for half a
 * 		periode with their specified PWM cycle, and off for the other half.
 *  Paramters: Pulse Width Modulation duty cycle in percent, and period
 * 		length. These paramters determine the dimming of the LEDs by
 * 		providing The OE' pin on the TLC5927 with a dimming frequency.
 * 		d_num describes the driver on the EVM that will execute this mode.
 * 		each driver also recieves a 16 bit sequence outlining the channels
 * 		that will be on/off.  The global blinking periode that will enable
 * 		the device to switch between PWM and off.
 *  Return:
 */
 void global_blink(char duty, char period, unsigned int seq_R, unsigned int seq_G,
 				  unsigned int seq_B, char blink_period)
 {

 }

/*
 *  Function: latch_out
 *  Description: This function latches on/off sequence to the output register, but
 * 		does not modify the OE' pin on the LED drivers, it also latches configuration
 * 		code to the configuration code register.  Function should be executed
 * 		in normal mode or special mode to write 16 bit configuration code.
 *  Paramters: Each driver recieves a 16 bit sequence outlining the channels
 * 		that will be on/off.
 *  Return:
 */
 void latch_out(unsigned int seq_R, unsigned int seq_G, unsigned int seq_B)
 {
 	 while (!(IFG2 & UCB0TXIFG));              // USCI_B0 TX buffer ready
 	 UCB0TXBUF = (char)seq_G;				   // TX OUT15 - OUT8 intructions for
 	 while (!(IFG2 & UCB0TXIFG)); 			   //	Green LED driver.  Lsb first.
 	 UCB0TXBUF = (char)(seq_G >> 8);		   // Transmit OUT7-OUT0

 	 while (!(IFG2 & UCB0TXIFG));
 	 UCB0TXBUF = (char)seq_R;
 	 while (!(IFG2 & UCB0TXIFG));
 	 UCB0TXBUF = (char)(seq_R >> 8);

 	 while (!(IFG2 & UCB0TXIFG));
 	 UCB0TXBUF = (char)seq_G;
 	 while (!(IFG2 & UCB0TXIFG));
 	 UCB0TXBUF = (char)(seq_B >> 8);
 	 while (!(IFG2 & UCB0TXIFG));

 	 P1OUT |= BIT4;								// Pulse LE to store to output
 	 _delay_cycles(1);							//	register.
 	 P1OUT &= ~BIT4;
 }

 /*
 *  Function: pwm_config
 *  Description: Utilizes timerA to produce a pwm output on the OE' pin
 * 		of the LED driver.  To be utilized in normal mode to choose dimm on
 * 		LEDs and to turn them on.
 *  Paramters: User provided 1/2 duty cycle and 1/2 period that the
 * 		LEDs are to be turned off. 1/2 period must be less than 0xFFFF clock
 * 		cycles.
 *  Return: none
 */
 void pwm_config( unsigned char half_duty, unsigned char half_period)
 {
  P2DIR |= BIT1;							//configure p1.2 for pwm out to OE'
  P2SEL |= BIT1;

  TA1CCR0 = half_period;
  TA1CCTL1 = OUTMOD_6;                      // CCR1 toggle/set
  TA1CCR1 = half_period - half_duty;        // CCR1 PWM duty cycle
  TA1CTL = TASSEL_2 + MC_3;                 // SMCLK, up-down mode
 }

  /* NOTE: I may not need this function since latch_out does everything this does
 *  Function: special_mode
 *  Description: Execute rx/tx communication via SPI with TLC5927 to command the devices
 * 		to store a new current configuration code. See TLC5927 datasheet for
 * 		switch description and protocol.
 *  Parameters: 16 bit current configuration code to be written to the current
 * 		configuration latch.  Each driver on the EVM must be given a code even if no
 * 		change in current is desired.
 *  Return: none
 * */
void special_conf(unsigned int config_code_R, unsigned int config_code_G,
 					unsigned int config_code_B)
{

}

unsigned int special_err()
{
	/* period 0 */
 	P1OUT = OE;							  	 // Set OE' as high and set
 	P1SEL &= ~SCLK;						  	 // SCLK as regular output
 	P1SEL2 &= ~SCLK;						 // low slave clock
 	_delay_cycles(6);

 	P1OUT |= SCLK;							 // high slave clock
 	_delay_cycles(6);

 	/* period 1 */
 	P1OUT &= ~SCLK;  						 // low slave clock
 	_delay_cycles(3);
 	P1OUT &= ~OE;
 	_delay_cycles(3);

 	P1OUT |= SCLK;							 // high slave clock
 	_delay_cycles(6);

 	/* period 2 */
 	P1OUT &= ~SCLK;
 	_delay_cycles(6);

 	P1OUT |= SCLK;
 	_delay_cycles(6);

 	/* period 3 */
 	P1OUT &= ~SCLK;
 	_delay_cycles(6);

 	P1OUT |= SCLK;
 	_delay_cycles(6);

 	_delay_cycles(38);						  // delay > 2us for error code
 											  // 	to be written
 	/* Read Error Detection Code */
 	/* THIS MAY NOT WORK!!! */
 	P1OUT |= OE;
 	UCB0TXBUF = 0x0000;

 	return UCB0RXBUF;
}

  /*
 *  Function: switch_mode
 *  Description: MCU communication via LE and OE' pins of TLC5927 to command the devices
 * 		to engage in mode switching between special mode and normal mode.
 *  Parameters: mode = 0 to switch from normal to special mode, and mode = 1 to switch
 * 		from special mode to normal mode.
 *  Return: none
 */
 void switch_mode(unsigned char mode)
 {
 	/* period 1 */
 	P1OUT = OE;							  	 // Set OE' as high and set
 	P1SEL &= ~SCLK;						  	 // SCLK as regular output
 	P1SEL2 &= ~SCLK;						 // low slave clock
 	_delay_cycles(6);

 	P1OUT |= SCLK;							 // high slave clock
 	_delay_cycles(6);

 	/* period 2 */
 	P1OUT &= ~SCLK;  						 // low slave clock
 	_delay_cycles(3);
 	P1OUT &= ~OE;
 	_delay_cycles(3);

 	P1OUT |= SCLK;							 // high slave clock
 	_delay_cycles(3);
 	P1OUT |= OE;
 	_delay_cycles(3);

 	/* period 3 */
 	P1OUT &= ~SCLK;
 	_delay_cycles(6);

 	P1OUT |= SCLK;
 	_delay_cycles(6);

 	/* period 4 */
 	P1OUT &= ~SCLK;
 	_delay_cycles(3);
 	if (mode == 0)
 		P1OUT &= LE;
 	_delay_cycles(3);

 	P1OUT |= SCLK;
 	_delay_cycles(3);
 	if (mode == 0)							  // switch to special/normal
 		P1OUT |= ~LE;
 	_delay_cycles(3);

 	/* period 5 */
 	P1OUT &= ~SCLK;
 	_delay_cycles(6);

 	P1OUT |= SCLK;
 	_delay_cycles(6);

 	P1OUT &= ~SCLK;							  // reset slave clk
 	_delay_cycles(6);
 }

/*
 *  Function: default_prog
 *  Description: run default led sequence out of the box
 *  Parameters: none
 *  Return: none
 */
void default_prog()
{

}

/*
 *  Function: prog_1
 *  Description: Run LED sequence number 1
 *  Parameters: none
 *  Return: none
 */
void prog_1()
{

}

/*
 *  Function: prog_2
 *  Discription: Run LED sequence number 2
 *  Return: none
 *  Parameters: none
 */
void prog_2()
{

}
