DRV2700: DRV2700 EVM

Part Number: DRV2700

Hi Sir,

Would dyou pls help questions for using DRV2700 EVM? Thanks.

  1. Standard Drive: setting ”Standard_Setting.png”, measure waveform are ”Standard_Input.png” & “Standard_Output.png”. >> It's correct.
  2. WaveBuilder: no matter using triangle/sine/impulse wave(pls reference WaveBuilder_Triangle.png & WaveBuilder_Sine.png & WaveBuilder_Impulse.png),

a. input have no waveform (pls reference WaveBuilder_Input.png).

b. output(-) also have no waveform, but output(+) will have 200V o/p(pls reference WaveBuilder_Output.png).

Would you pls help to advise what'w wrong? Thanks.

drv2700.zip

Thanks, Ian.
