UCC2813-2 PSpice Model error

Other Parts Discussed in Thread: UCC2813-2, UCC2813-1

Hi,

I have downloaded the ORCAD PSPICE model from TI website & I am getting the below mentioned DRC error message in both the schematics (UCC2813-2 and UCC2813-2).

Please help me to fix this error.

http://focus.ti.com/docs/prod/folders/print/ucc2813-2.html

http://focus.ti.com/docs/prod/folders/print/ucc2813-1.html



ucc2813-2
--------------------------------------------------
Checking Schematic: Startup
--------------------------------------------------
Checking Electrical Rules
WARNING:  [DRC0004]  Possible pin type conflict U1,GND Bidirectional Connected to Power
                    Startup, PAGE1  (5.50, 3.00)

Checking for Unconnected Wires

Checking Off-Page Connections

Checking Pin to Port Connections

--------------------------------------------------
Checking Schematic: Steady_State
--------------------------------------------------
Checking Electrical Rules
WARNING:  [DRC0004]  Possible pin type conflict U1,GND Bidirectional Connected to Power
                    Steady_State, PAGE1  (5.70, 3.00)

Checking for Unconnected Wires

Checking Off-Page Connections

Checking Pin to Port Connections



ucc2813-1
--------------------------------------------------
Checking Schematic: Startup
--------------------------------------------------
Checking Electrical Rules
WARNING:  [DRC0004]  Possible pin type conflict U1,GND Bidirectional Connected to Power
                    Startup, PAGE1  (4.60, 3.00)

Checking for Unconnected Wires

Checking Off-Page Connections

Checking Pin to Port Connections

--------------------------------------------------
Checking Schematic: Steady_State
--------------------------------------------------
Checking Electrical Rules
WARNING:  [DRC0004]  Possible pin type conflict U1,GND Bidirectional Connected to Power
                    Steady_State, PAGE1  (4.70, 3.20)

Checking for Unconnected Wires

Checking Off-Page Connections

Checking Pin to Port Connections



Thanks and Regards

C.K.Gowda
