Part Number: CC2511USB_REFDES
Other Parts Discussed in Thread: CC2511

Hi:

Hello, recently I am studying to use CC2511F32RSP this chip to make a USB_nano_dongle; I see ti company has reference schematic, pcb, but I have no experience in this part of pcb antenna, I want to directly use your original PCB antenna reference design. Can you send all the source files of your company named "CC2511_USB_Nano_Dongle_LAYOUT_1_1" to me for reference, especially pcb files. Thank you.

over 6 years ago

0 SVG over 6 years ago

TI__Prodigy 250 points

Hi,

The design and gerber files can be downloaded from TI site: http://www.ti.com/general/docs/lit/getliterature.tsp?baseLiteratureNumber=swrc062&fileType=zip

Inverted F antenna gerber and dxf files are named IFA_USB.spl and IFA_USB.dxf

Regards,
Sven

0 user3718418 over 6 years ago in reply to SVG

Prodigy 50 points

Hello Sven：

Thank you for your reply！

recently I am studying to use CC2511F32RSP this chip to make a USB_nano_dongle，The board I made is very small, so I want to design like this pcb antenna, as shown in the attached documentation below. Ti company has corresponding reference design sch and pcb, please send me the same source file of the same PCB antenna reference design as the picture. Thanks again!

Regards,

Andrew

CC2511_USB_Nano_Dongle_LAYOUT_1_1.pdf CC2511_USB_Nano_Dongle_SCHEMATIC_1_1.pdf

0 SVG over 6 years ago in reply to user3718418

TI__Prodigy 250 points

Hello Andrew,

Attaching zip file with design files.

Regards,
Sven

CC2511_USB_Bean_Dongle_1_1.zip

0 user3718418 over 6 years ago in reply to SVG

Prodigy 50 points

Hello Sven：

The pcb antenna in this pdf file is what I want：

Thank you very much. This is the source file I want.
But I have a question: I opened the file and found out why there is no antenna part? (I just want to use the reference design of the PCB antenna directly) Is there data loss? The software I use is cadstar 16.

Regards,

Andrew

0 user3718418 over 6 years ago in reply to user3718418

Prodigy 50 points

Dear Sven:

Please take the time to reply to my email above, thank you, thank you very much!

Andrew

Regards！

0 SVG over 6 years ago in reply to user3718418

TI__Prodigy 250 points

Hi,

Please see if you can open this library (Cadstar 12).

Antenna_mini_dongle.lib

Regards
