TSW1400EVM: TSW1400EVM PCB design files(Altium Designer or Cadence file)

xulirui96

Part Number: TSW1400EVM

Hello, Ti engineers，
Merry Christmas, I am using AFE to design a data acquisition circuit. I have used AFE+TSW1400EVM to complete the evaluation. Now I need to design our own circuit board. We are going to use TSW1400EVM as a reference. Could you please share the TSW1400EVM PCB design file (Altium Designer or Cadence file), it will be of great help to us if possible.

over 4 years ago

0 xulirui96 over 4 years ago

Prodigy 210 points

Preferably Altium Designer files，I don't have Cadence software

0 jim s over 4 years ago in reply to xulirui96

TI__Guru* 91947 points

Xulirui,

The only design files we have are Cadence based. You can download these from the TSW1400EVM product folder on the TI website. You may be able to find a conversion tool that will convert this design into Altium.

Regards,

Jim

0 xulirui96 over 4 years ago in reply to jim s

Prodigy 210 points

OK, got it, Thank you!

0 xulirui96 over 4 years ago in reply to jim s

Prodigy 210 points

Hi Jim,

Thank you for your reply. In fact, I downloaded the design file from the TSW1400EVM product folder on the TI website(slac514). Recently I tried to open this file with Cadence software, but I found that it does not look like a Cadence file, and I can’t open it with cadence software.
The first picture below is a typical Cadence project, and the second picture is a slac514 file, I cannot open the file in any folder.

FIG.1 A Typical Cadence Project

FIG.2 slac514
