TPS23731: Schematic check request

Tommy Tzeng

Part Number: TPS23731

Hi Sir,

as attached, may we know whether this schematic is ok? we need double confirm, thanks for your help and support.

1. this project has two power source, when the adapter is insert, the PD need to turn off, so corresponding APD circuit is add.

2. this project need to detect AT/AF mode, so there is a new T2P related circuit in the PD.

MiEAP-3270BE_SCH_C2_80_v001_20240320_TPS23731_Review-已壓縮.pdf

over 1 year ago

0 Diang Xing over 1 year ago

TI__Mastermind 37101 points

Hi Tommy,

Thanks for reaching out!

I am handling the PoE PD review but I will be out of office until end of March. I would recommend you to go though the schematic check list and let me know if you have any further questions or concerns.

2806.PoE Layout Check LIst.xlsx 2806.PoE Schematic Checklist.xlsx

Best regards,

Diang

0 Tommy Tzeng over 1 year ago in reply to Diang Xing

Genius 5780 points

Hi Sir,

thanks for you data and we will refer to these suggested data.

in the meantime, we can get your preliminary suggestion or improvement for this schematic? before the end of the month.

0 Brandon Beader over 1 year ago in reply to Tommy Tzeng

TI__Genius 15275 points

Hi Tommy,

Diang is out of office. Please use schematic check list to do prelimary review. Once Diang is back in office, we will review in a timely manner. Thanks for your patience!

Regards,

Brandon
