TPS1HB50-Q1: EXAMPLE BOARD LAYOUT dimension

Kazuhiko Hirano
Genius 15418 points
Part Number: TPS1HB50-Q1
Other Parts Discussed in Thread: TPS1HB35-Q1

Tool/software:

Hello,

Datasheet Figure 12-1 shows 16-PWP Layout Example.
However there are no dimensions for via diameter, power pad and rand pattern.
My customer would like to know TI recommended dimension for them.
Could you provide recommended 16-PWP Layout Example having dimensions?

Best regards,

K.Hirano
