UCC25661EVM-128: Request for Design and Gerber Files for UCC25661EVM-128 Evaluation Board

Mohd Sahid
Prodigy 80 points
Part Number: UCC25661EVM-128
Other Parts Discussed in Thread: UCC25661

Tool/software:

Dear TI Support Team,

I am currently evaluating the UCC25661EVM-128 evaluation board as part of a power supply development project. To support our ongoing design and customization efforts, I would like to kindly request the following files related to this evaluation board:

  1. Schematic and PCB layout files (native design files, if available)
  2. Gerber files

Any additional design documentation or mechanical drawings

These resources will be very helpful in understanding the implementation and making necessary adaptations for our application.
Please let me know if additional steps are required to obtain this information.

Thank you for your support.

Best regards,
Mohd Sahid
E-mail : contact@nakeletronics.com

  • 0
    TI__Genius 12795 points

    Mohd,

    There are many other designs with gerber/layout you can refer to. Is there any reason you cannot use them?

    https://www.ti.com/product/UCC25660

  • 0 in reply to Ning Tan
    Prodigy 80 points

    Dear Ning,

    Thank you for your prompt response.

    I truly appreciate your suggestion regarding the available reference designs. However, at this stage of our development, our focus is specifically on the LLC power stage, and the UCC25661EVM-128 evaluation board aligns very well with our design objectives and system architecture.

    As this board already implements an optimized LLC topology using the UCC25661, having access to its schematic, PCB layout, and Gerber files would greatly assist us in better understanding the design and efficiently customizing it for our application. It would also help us ensure performance consistency and accelerate the debugging process.

    Thank you once again for your continued support and guidance.

    Best regards,
    Mohd Sahid
    Email: contact@nakeletronics.com

  • +1 in reply to Mohd Sahid
    TI__Genius 12795 points

    UCC25660x and UCC25661x can use the same design. Only minor configuration change. Unless you plan to copy and paste the EVM design, which is highly unlikely, you will need to do modification work anyway. Please start with the ref design online first. I also suggest you to go through the design calculator to confirm.

    Best
