TPS2561: USB 2.0 plug

kevin p

Part Number: TPS2561

Hi team,

I want to use TPS2561 as a current limited power switch, there is no battery in the schematic, there are some DC/DC and MCU in the schematic. the USB port Connect to the computer, USB provides power and communication with MCU. whether TPS2561 can withstand normal plugging and unplugging the USB cable which connected with computer? The schematic is as below, please review, thank you.

over 6 years ago

0 Kevin-Cheng over 6 years ago

TI__Expert 3135 points

Hi,

I can't see the schematic, can you upload the schematic as an attachment. After receiving the schematic, my colleagues will provide you with specific support.

Best Regards,

Kevin

0 kevin p over 6 years ago in reply to Kevin-Cheng

Intellectual 470 points

4848.SCHEMATIC.pdf

0 kevin p over 6 years ago in reply to Kevin-Cheng

Intellectual 470 points

Hi Kevin,
I have uploaded the schematic, please review.
Does the TPS2561 can support to hot swap? I want to plug and unplug the USB cable usually, will the TPS2561 be damaged? thank you.

0 kevin p over 6 years ago in reply to kevin p

Intellectual 470 points

Hi Kevin,
I added some information, The PCBA connect witch the computer's USB port by a cable, the PCBA normal operating current is 150mA max , the PCBA need to meet USB2.0 requirement.I want to plug and unplug the USB cable usually, will the TPS2561 be damaged? thank you.

0 Ziv Zhang over 6 years ago in reply to kevin p

TI__Mastermind 18031 points

Hi Kevin,

Yes, TPS2561 can support hot swap. It's just a power switch.

But, as hot swap, will generate the current/voltage overshoot, should confirm if it's ok for MCU.

If you have big concern with this, you can send me the hardware to me. I can have a test for you.

Or I can send some samples of TPS2561 for you to have a test.

Please leave your email address to me. I can contact you.

If any, contact me any time.

If you think this is your answer, please click 'issue is solved' button.

Thanks.

Ziv

0 kevin p over 6 years ago in reply to Ziv Zhang

Intellectual 470 points

Hi Ziv,

Thanks for your support.
Due to the delay time of TPS2561 when power on and the MCU can work on 6.5V, I think the MCU can work normally，
Don't concern about the MCU in this condition.

Since I have no hardware yet. Could you help to evaluate the IC of TPS2561,Does TPS2561 can work normally when hot swap the usb cable?the schematic as above.

Thanks.

Kevin

0 Ziv Zhang over 6 years ago in reply to kevin p

TI__Mastermind 18031 points

Hi Kevin,

Will reply to you thursday or friday.

Thanks.

Ziv

0 kevin p over 6 years ago in reply to Ziv Zhang

Intellectual 470 points

Hi Ziv,

Thanks for your support.

When you are simulating, you can adjust the value of input and output capacitors of the TPS2561 , until the circuit meet the USB2.0 hot swap, the TPS2561 work normally.

Thanks.

Kevin

0 Ziv Zhang over 6 years ago in reply to kevin p

TI__Mastermind 18031 points

Hi Kevin,

Sorry for that, the part I applied on TI store not arrive my location on time.
I think this two days I can get the part.
Then will test for you.
Sorry for the delay.
Will tell you the results soon.

Thanks.

0 Ziv Zhang over 6 years ago in reply to Ziv Zhang

TI__Mastermind 18031 points

Hi Kevin,

I have answer your question from your another same questioning. The link is as following.
e2e.ti.com/.../2989235
I will first close the question first.
If you have other concern, contact me any time.
Thanks.

Ziv
