Hello, normally I can find STEP files of TI packages fairly easily but the LP503x series uses a weird 6mm x 5mm 46 pin QFN. I can't find this STEP file anywhere - I assume that TI has it, can you please provide?
Thanks,
Derek
This thread has been locked.
If you have a related question, please click the "Ask a related question" button in the top right corner. The newly created question will be automatically linked to this question.
Hello, normally I can find STEP files of TI packages fairly easily but the LP503x series uses a weird 6mm x 5mm 46 pin QFN. I can't find this STEP file anywhere - I assume that TI has it, can you please provide?
Thanks,
Derek
Hi Derek,
Proper engineer has been assigned to look at this and will reply to you soon.
Hello, STEP file is a 3D file format which we electronic engineers use to generate a 3D model of the part for checking the footprint and ensuring that it is not hitting anything. All the major 3D mechanical design software packages can output them, so whoever designed the package can easily create it.
I use www.3dcontentcentral.com to find a lot of the normal packages, although many manufacturers provide them directly. As an example, just google QFN STEP file and you'll see a lot of results.
Thanks,
Derek
