BOOSTXL-PGA460: Step file

Mohamed BOUICH

Part Number: BOOSTXL-PGA460
Other Parts Discussed in Thread: PGA460, MSP-EXP430F5529LP, , PGA460-Q1

Hello,

I am looking for the step file of the two following board used for PGA460 evaluation :

MSP-EXP430F5529LP https://www.ti.com/store/ti/en/p/product/?p=MSP-EXP430F5529LP

BOOSTXL-PGA460 https://www.ti.com/store/ti/en/p/product/?p=BOOSTXL-PGA460

I want to realize an housing for a demonstration. Could you please provide me these files ?

Thank you.

Mohamed.

over 5 years ago

0 Akeem Whitehead over 5 years ago

TI__Mastermind 27950 points

Hi Mohamed,

There is a STEP file available for the MSP-EXP430F5529LP here: https://e2e.ti.com/support/microcontrollers/msp430/f/166/t/750182?MSP-EXP430F5529LP-Need-step-file-of-launch-pad-board-for-dimensions-to-mount-into-fixture

We do not have a STEP file available for the BOOSTXL-PGA460. However, you could stack two MSP-EXP430F5529LP STEP files to emulate the TI LaunchPad-BoosterPack stacked hardware setup of the PGA460-Q1 EVM.

0 Akeem Whitehead over 5 years ago in reply to Akeem Whitehead

TI__Mastermind 27950 points

Mohamed,

Update: I've generate and attached a STEP file of the BOOSTXL-PGA460; however, the master-board and daughter-card are merged as a single board (this is how the EVM is manufactured), rather than the actual perpendicular configuration of the PGA460-Q1 EVM. If you have the ability to separate the two, and rotate the daughter-card, you will have the operation 3D perspective of the EVM.

https://e2e.ti.com/cfs-file/__key/communityserver-discussions-components-files/1023/BOOSTXL_2D00_PGA460_5F00_STEP.step
