MAX3221E: is not working different lot

Mehmet YILDIZ

Part Number: MAX3221E

Hi, i have max221E device that has 2 different lots.

the below code is working

the below code is not working.

As you can see this is the same code but only some lot numbers are different. Maybe the last picture product can be an old date code.

How can I fix the problem because i assembled it and it is very difficult to replace it?

0 Clemens Ladisch over 1 year ago

Guru 316940 points

Please show the schematic, and oscilloscope traces of the logic and RS-232 signals.

Did you get these from an authorized distributor?

0 Mehmet YILDIZ over 1 year ago in reply to Clemens Ladisch

Hello, the schematic is below,

i bought from our local reseller. you can find the box information

0 Clemens Ladisch over 1 year ago in reply to Mehmet YILDIZ

Guru 316940 points

Pin 16 is a control input and must not be left floating.

0 Mehmet YILDIZ over 1 year ago in reply to Clemens Ladisch

what it will be, high or low ?

+1 Clemens Ladisch over 1 year ago in reply to Mehmet YILDIZ

Guru 316940 points

Pin 16 must be pulled high during normal operation.

0 Mehmet YILDIZ over 1 year ago in reply to Clemens Ladisch

cna we short circuit with 15 to 16 due to 15 is vcc.

0 Clemens Ladisch over 1 year ago in reply to Mehmet YILDIZ

Guru 316940 points

Yes.

+1 BOBBY over 1 year ago in reply to Mehmet YILDIZ

Hi Mehmet,

Mehmet YILDIZ said:
cna we short circuit with 15 to 16 due to 15 is vcc.

Are you cable to confirm if this resolved your issue?

-Bobby

0 Mehmet YILDIZ over 1 year ago in reply to BOBBY

thanks for the support. It worked.
