SN6501-Q1: Multiple Output Configuration

Shinichi Yokota

Part Number: SN6501-Q1

Hello,

Is it doable to form a multiple output configuration with SN6501-Q1? Each output has a LDO which eventually generates more than 5.5 V to its load and the load current of each output will be roughly 10 mA or less. Reserve current protection diodes will be placed between the SN6501-Q1 circuit and each LDO, So, the output voltage of the SN6501-Q1 circuit on the secondary side after rectifiers must be roughly 1 V (V_F + V_DROPOUT) higher than the LDO output.

Best regards,
Shinichi Yokota

over 7 years ago

0 Lucas Schulte9 over 7 years ago

TI__Expert 6955 points

Yokota-san,

This seems doable since the load current is only 10mA per LDO. Would you be able to be more specific on what LDO output voltages be? This will determine the best turns ratio for this application.

Respectfully,

Lucas Schulte

0 Shinichi Yokota over 7 years ago in reply to Lucas Schulte9

TI__Genius 9715 points

Schulte-san,

I can only say the LDO voltage must be more than 5.5 V. The load current will change from 0 to around 10 mA respectively depending on its operating conditions.

Best regards,
Shinichi Yokota

0 Lucas Schulte9 over 7 years ago in reply to Shinichi Yokota

TI__Expert 6955 points

Yokota-san,

This application should work since the power requirement is low.

Respectfully,
Lucas Schulte
