Part Number: TIDM-TMS570BMS
Dear Sir/Madam:
The Design Reference Title: TMS570 Active Cell-Balancing Battery Management Design Guide (TIDM-TMS570BMS)
Hardware: TMS570 LS0432 MCU; EMB1402 EVM
Software: HALCoGen; Code Composer Studio
The table (Please see table) shows the EMB1402 EVM (Please see green board) device connected to the Launchpad TMS570 (Please see red board) by J3. J3 (Please see images below) is meant to connect to the batteries. The connection to the batteries should not serve a second purpose of connecting to the Launchpad TMS570.
The following is a list of questions on connecting these devices.
(a) Was this a "typo" error? If not,
(b) How are the batteries and Launchpad TMS570 connected to the EMB1402 EVM?
