EK-TM4C1294XL: Ethernet recieve speed.

R & D

Part Number: EK-TM4C1294XL

Hi,

I have created TCP server and is receiving data from client successfully, same data is to be written to USB Drive that also works fine. My issue is that client is sending 4 Bytes buffer at speed rate >2.5Mbps (tested PC as a server using Hercules and Wireshark both), at same speed TM4C server is not receiving data.

Regards

Khodidas

/*
 * Copyright (c) 2014-2015, Texas Instruments Incorporated
 * All rights reserved.
 *
 * Redistribution and use in source and binary forms, with or without
 * modification, are permitted provided that the following conditions
 * are met:
 *
 * *  Redistributions of source code must retain the above copyright
 *    notice, this list of conditions and the following disclaimer.
 *
 * *  Redistributions in binary form must reproduce the above copyright
 *    notice, this list of conditions and the following disclaimer in the
 *    documentation and/or other materials provided with the distribution.
 *
 * *  Neither the name of Texas Instruments Incorporated nor the names of
 *    its contributors may be used to endorse or promote products derived
 *    from this software without specific prior written permission.
 *
 * THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
 * AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO,
 * THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
 * PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR
 * CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
 * EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
 * PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;
 * OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,
 * WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
 * OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE,
 * EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
 */

/*
 *    ======== tcpEcho.c ========
 *    Contains BSD sockets code.
 */
#include <stdint.h>
#include <stdbool.h>
#include <stdio.h>
#include <string.h>
#include <stdlib.h>

#include <xdc/std.h>
#include <xdc/runtime/Error.h>
#include <xdc/runtime/System.h>

#include <ti/sysbios/BIOS.h>
#include <ti/sysbios/knl/Task.h>
#include <ti/drivers/GPIO.h>
#include <ti/drivers/UART.h>
/* NDK BSD support */
#include <sys/socket.h>

/* Example/Board Header file */
#include "Board.h"

#include "inc/hw_memmap.h"
#include "inc/hw_adc.h"
#include "driverlib/adc.h"
#include "driverlib/gpio.h"
#include "inc/hw_ints.h"
#include "driverlib/interrupt.h"
#include "inc/hw_sysctl.h"
#include "driverlib/sysctl.h"
#include "driverlib/ssi.h"
#include "driverlib/pin_map.h"


//****************************For USB************************//
//#include "usblib/usblib.h"
//#include "usblib/usbmsc.h"
//#include "usblib/host/usbhost.h"
//#include "usblib/host/usbhmsc.h"
#include <ti/drivers/USBMSCHFatFs.h>
#include "fatfs/src/ff.h"

//#include <ti/sysbios/fatfs/ff.h>
//#include <ti/sysbios/fatfs/diskio.h>.
  FILE src, dst;

  USBMSCHFatFs_Handle usbmschfatfsHandle;
  USBMSCHFatFs_Params usbmschfatfsParams;


#define USB_DRIVE_NUM 0
const char textarray[] = "0123456789abcdefghijklmnopqrstuvwxyz012\n";
const char  inputfilesd[]  = "input.txt";

static uint8_t usbServiceTaskStack[1024];

char read_buf[20];
unsigned int filesize,fresult;

unsigned int bytesWritten = 0;
//*********************************************************************//

UART_Handle      handle;
UART_Params myuart;


#define NUM_SSI_DATA    5

#define TCPPACKETSIZE 4
#define NUMTCPWORKERS 50
uint32_t bytesRcvd;


uint32_t adcBuffer2[9];
uint32_t pui32DataTx[NUM_SSI_DATA];
uint32_t pui32DataRx[NUM_SSI_DATA];
uint32_t ui32SysClock=0;
uint32_t ui32Index;
char buffer[TCPPACKETSIZE];

bool LOCK=false;


uint16_t counter;
int                clientfd;

void USB_INIT();

void ADC0IntHandler(void)
{
    // Clear interrupt Flag
    ADCIntClear(ADC0_BASE, 0);
    ADCSequenceDataGet(ADC0_BASE, 0, adcBuffer2);
    ADCProcessorTrigger(ADC0_BASE, 1);
    //ADCSequenceDataGet(ADC0_BASE, 0, adcBuffer2);
    ADCSequenceDataGet(ADC0_BASE, 1, &adcBuffer2[6]);
    ADCSequenceDataGet(ADC0_BASE, 1, &adcBuffer2[7]);
    ADCSequenceDataGet(ADC0_BASE, 1, &adcBuffer2[8]);
    if(adcBuffer2[8]>4000)
    {
     LOCK=true;
    }
}

void adc2_init(void)
 {

     uint32_t adcClock=0, adcDiv=0;
        // Enable the ADC0 peripheral
        SysCtlPeripheralEnable(SYSCTL_PERIPH_ADC0);


        SysCtlPeripheralEnable(SYSCTL_PERIPH_GPIOD);
        GPIOPinTypeADC(GPIO_PORTD_BASE,  GPIO_PIN_5 | GPIO_PIN_4 | GPIO_PIN_3| GPIO_PIN_2| GPIO_PIN_1 | GPIO_PIN_0);
        SysCtlPeripheralEnable(SYSCTL_PERIPH_GPIOD);



        SysCtlPeripheralEnable(SYSCTL_PERIPH_GPIOE);
        GPIOPinTypeADC(GPIO_PORTE_BASE, GPIO_PIN_5| GPIO_PIN_1 | GPIO_PIN_2); //| GPIO_PIN_3);
        // Configure the ADC to use PLL at 480 MHz with Full rate devided by 30 to get 16 MHz
        ADCClockConfigSet(ADC0_BASE, ADC_CLOCK_SRC_PLL | ADC_CLOCK_RATE_FULL, 30);


        ADCSequenceDisable(ADC0_BASE, 0);
        ADCSequenceDisable(ADC0_BASE, 1);
        // Read the current ADC configuration
        adcClock=ADCClockConfigGet(ADC0_BASE, &adcDiv);
        // Hardware averageing: by a faktor of 2 -> 2,4,8,16,32,64
        ADCHardwareOversampleConfigure(ADC0_BASE, 8);
        // ADC voltage-lvl reference set to intern
        ADCReferenceSet(ADC0_BASE, ADC_REF_INT);
        ADCReferenceSet(ADC0_BASE, ADC_REF_INT);
        // ADC Sequencer config: Source ADC0, Sequencer 0, Trigger: always, priority: 0
        ADCSequenceConfigure(ADC0_BASE, 0, ADC_TRIGGER_ALWAYS, 0);
        ADCSequenceConfigure(ADC0_BASE, 1, ADC_TRIGGER_PROCESSOR, 0);


        // ADC Sequencer step
        // 1. Source-ADC -> ADC0_BASE
        // 2. Source-Sequencer -> 0
        // 3. Sample-Value depends in the depth of the FIFO, by Sequencer 0 it is up to 7 (0-7)
        // 4. Config-> select input-channel AINx, interrupt specification
        //
        ADCSequenceStepConfigure(ADC0_BASE, 1, 0, ADC_CTL_CH1);
        ADCSequenceStepConfigure(ADC0_BASE, 1, 1, ADC_CTL_CH2);
        ADCSequenceStepConfigure(ADC0_BASE, 1, 2, ADC_CTL_CH8 |ADC_CTL_IE|ADC_CTL_END);

       // ADCSequenceStepConfigure(ADC0_BASE, 0, 0, ADC_CTL_CH4);
        //ADCSequenceStepConfigure(ADC0_BASE, 0, 1, ADC_CTL_CH5);

        ADCSequenceStepConfigure(ADC0_BASE, 0, 0, ADC_CTL_CH6);
        ADCSequenceStepConfigure(ADC0_BASE, 0, 1, ADC_CTL_CH7);

        ADCSequenceStepConfigure(ADC0_BASE, 0, 2, ADC_CTL_CH12);
        ADCSequenceStepConfigure(ADC0_BASE, 0, 3, ADC_CTL_CH13);
        ADCSequenceStepConfigure(ADC0_BASE, 0, 4, ADC_CTL_CH14);
        ADCSequenceStepConfigure(ADC0_BASE, 0, 5, ADC_CTL_CH15 |ADC_CTL_IE|ADC_CTL_END );


        IntPrioritySet(INT_ADC0SS0, 0x00);

           // ADC0SS0 Interrupt source
           ADCIntRegister(ADC0_BASE, 0, ADC0IntHandler);

           // Register Interrupt to NVIC
           IntRegister(INT_ADC0SS0, ADC0IntHandler);

           // ADC0 enable
           ADCIntEnable(ADC0_BASE, 0);

           // Interrupt ADC0SS0 enable
           IntEnable(INT_ADC0SS0);

           // Enable Global Interrupts
           IntMasterEnable();

           ADCSequenceEnable(ADC0_BASE, 0);
           ADCSequenceEnable(ADC0_BASE, 1);

 }
void SPI_Init()
{
    // The SSI0 peripheral must be enabled for use.
    SysCtlPeripheralEnable(SYSCTL_PERIPH_SSI0);
    SysCtlPeripheralEnable(SYSCTL_PERIPH_GPIOA);

    GPIOPinConfigure(GPIO_PA2_SSI0CLK);
    GPIOPinConfigure(GPIO_PA3_SSI0FSS);
    GPIOPinConfigure(GPIO_PA4_SSI0XDAT0);
    GPIOPinConfigure(GPIO_PA5_SSI0XDAT1);
    GPIOPinTypeSSI(GPIO_PORTA_BASE, GPIO_PIN_5 | GPIO_PIN_4 | GPIO_PIN_3 | GPIO_PIN_2);
    // Configure and enable the SSI port for SPI master mode.  Use SSI0, system clock supply, idle clock level low and active low clock in
    // freescale SPI mode, master mode, 1MHz SSI frequency, and 8-bit data.
    // For SPI mode, you can set the polarity of the SSI clock when the SSI unit is idle.  You can also configure what clock edge you want to
    // capture data on.  Please reference the datasheet for more information on the different SPI modes.
    SSIConfigSetExpClk(SSI0_BASE, ui32SysClock, SSI_FRF_MOTO_MODE_0, SSI_MODE_SLAVE, 1000000, 8);

    // Enable the SSI0 module.
    SSIEnable(SSI0_BASE);
}
/*
 *  ======== tcpWorker ========
 *  Task to handle TCP connection. Can be multiple Tasks running
 *  this function.
 */
//Void tcpWorker(UArg arg0, UArg arg1)
//{
//    int  clientfd = (int)arg0;
//
//    ui32SysClock=SysCtlClockFreqSet(SYSCTL_OSC_INT | SYSCTL_USE_PLL | SYSCTL_CFG_VCO_480, 120000000);
//
//    System_printf("tcpWorker: start clientfd = 0x%x\n", clientfd);
//
//
////    while (1)
////    {
////
////
////        pui32DataTx[0] = 's';
////        pui32DataTx[1] = 'p';
////        pui32DataTx[2] = 'I';
////        pui32DataTx[3] = 'S';
////        pui32DataTx[4] = '\n';
////   //     bytesRcvd = recv(clientfd, buffer, TCPPACKETSIZE, 0);
////        for(ui32Index = 0; ui32Index < NUM_SSI_DATA; ui32Index++)
////           {
////               // Send the data using the "blocking" put function.  This function
////               // will wait until there is room in the send FIFO before returning.
////               // This allows you to assure that all the data you send makes it into
////               // the send FIFO.
////               //
////               SSIDataPutNonBlocking(SSI0_BASE, pui32DataTx[ui32Index]);
////               //SSIDataGet(SSI0_BASE, &pui32DataRx[ui32Index]);
////               SSIDataGetNonBlocking(SSI0_BASE, &pui32DataRx[ui32Index]);
////           }
////
////
////         count++;
////
////
////       // bytesSent = send(clientfd, buffer, bytesRcvd, 0);
////
////    }
//    System_printf("tcpWorker stop clientfd = 0x%x\n", clientfd);
//
//    close(clientfd);
//}

/*
 *  ======== tcpHandler ========
 *  Creates new Task to handle new TCP connections.
 */
Void tcpHandler(UArg arg0, UArg arg1)
{
    int                status;

    int                server;
    struct sockaddr_in localAddr;
    struct sockaddr_in clientAddr;
    int                optval;
    int                optlen = sizeof(optval);
    socklen_t          addrlen = sizeof(clientAddr);
    Task_Handle        taskHandle;
    Task_Params        taskParams;
    Error_Block        eb;

    server = socket(AF_INET, SOCK_STREAM, IPPROTO_TCP);
    if (server == -1) {
        System_printf("Error: socket not created.\n");
        goto shutdown;
    }


    memset(&localAddr, 0, sizeof(localAddr));
    localAddr.sin_family = AF_INET;
    localAddr.sin_addr.s_addr = htonl(INADDR_ANY);
    localAddr.sin_port = htons(arg0);

    status = bind(server, (struct sockaddr *)&localAddr, sizeof(localAddr));
    if (status == -1) {
        System_printf("Error: bind failed.\n");
        goto shutdown;
    }

    status = listen(server, NUMTCPWORKERS);
    if (status == -1) {
        System_printf("Error: listen failed.\n");
        goto shutdown;
    }

    optval = 1;
    if (setsockopt(server, SOL_SOCKET, SO_KEEPALIVE, &optval, optlen) < 0) {
        System_printf("Error: setsockopt failed\n");
        goto shutdown;
    }

    while ((clientfd = accept(server, (struct sockaddr *)&clientAddr, &addrlen)) != -1)
    {

        System_printf("tcpHandler: Creating thread clientfd = %d\n", clientfd);

        /* Init the Error_Block */
        Error_init(&eb);

        USB_INIT();

        /* addrlen is a value-result param, must reset for next accept call */
        addrlen = sizeof(clientAddr);
    }




    System_printf("Error: accept failed.\n");

shutdown:
    if (server > 0) {
        close(server);
    }
}




void USB_INIT()
{

       /* Variables for the CIO functions */

       USBMSCHFatFs_Params_init(&usbmschfatfsParams);
         usbmschfatfsParams.serviceTaskStackPtr = usbServiceTaskStack;
         usbmschfatfsParams.serviceTaskStackSize = sizeof(usbServiceTaskStack);
         usbmschfatfsHandle = USBMSCHFatFs_open(Board_USBMSCHFatFs0,
                                                USB_DRIVE_NUM,
                                               &usbmschfatfsParams);
         if (usbmschfatfsHandle == NULL) {
             System_abort("Error starting the USB Drive\n");
         }
         else {
             System_printf("Drive %u is mounted\n", USB_DRIVE_NUM);
         }

         /* Need to block until a USB Drive has been enumerated */
         if (!USBMSCHFatFs_waitForConnect(usbmschfatfsHandle, 100000)) {
             System_abort("No USB drive present, aborting...\n");
         }

         adc2_init();
         SPI_Init();


         fresult = f_open(&src, inputfilesd, FA_READ|FA_WRITE);
              if (fresult != FR_OK)
                {
                     System_printf("Creating a new file \"%s\"...", inputfilesd);
                         /* Open file for both reading and writing */
                         fresult = f_open(&src, inputfilesd, FA_CREATE_NEW|FA_READ|FA_WRITE);
                         if (fresult != FR_OK)
                         {
                             System_printf("Error: \"%s\" could not be created.\n",inputfilesd);
                                           System_printf("Aborting...\n");
                         }

                         fresult =    f_write(&src, textarray, strlen(textarray), &bytesWritten);
                         f_sync(&src);
                         f_close(&src);
                         /* Reset the internal file pointer */
                        // f_lseek(&src, 0);
                         System_printf("done\n");
                 }
                    else
                     {
                         char temp[100];
                        // f_read(&src, read_buf, strlen(read_buf), &bytesRead);

                         while(1)
                         {

                             counter++;
                             bytesRcvd = recv(clientfd, buffer, TCPPACKETSIZE, 0);
                            // sprintf(temp,"%lu,%lu,%lu,%lu,%lu,%lu,%lu,%lu,%lu,%d,%d,%d,%d \n",adcBuffer2[0],adcBuffer2[1],adcBuffer2[2],adcBuffer2[3],adcBuffer2[4],adcBuffer2[5],adcBuffer2[6],adcBuffer2[7],adcBuffer2[8],buffer[0],buffer[1],buffer[2],buffer[3]);
                             sprintf(temp,"%d,%d,%d,%d \n",buffer[0],buffer[1],buffer[2],buffer[3]);
                             fresult = f_write(&src,temp, strlen(temp),&bytesWritten);
                                 //bytesRcvd = recv(clientfd, buffer, TCPPACKETSIZE, 0);

                                 //if(counter>5000)
                             if(LOCK)
                                 {
                                     f_sync(&src);
                                     f_close(&src);
                                     break;
                                 }
                         }

                     }
                     USBMSCHFatFs_close(usbmschfatfsHandle);
                    //System_printf("Drive %u unmounted\n", USB_DRIVE_NUM);
}


/*
 *  ======== main ========
 */
int main(void)

{
    /* Call board init functions */
    ui32SysClock = SysCtlClockFreqSet((SYSCTL_XTAL_25MHZ |SYSCTL_OSC_MAIN |SYSCTL_USE_PLL |SYSCTL_CFG_VCO_480), 120000000);
    Board_initGeneral();
    Board_initGPIO();
    Board_initEMAC();
    Board_initUSBMSCHFatFs();
    Board_initUART();


    UART_Params_init(&myuart);
    handle = UART_open(0, &myuart);
   // UARTStdioConfig(0, 115200, ui32SysClock);
    UART_write(handle, "HELLO", 5);

    /* SysMin will only print to the console when you call flush or exit */
    System_flush();

    /* Start BIOS */
    BIOS_start();

    return (0);
}

over 4 years ago

0 Charles Tsai over 4 years ago

TI__Guru**** 191906 points

Hi,

If you keep your code simple without the USB, ADC, SPI stuffs. In another word, just keep your code with the tcp server, at what speed can it sustain?

0 R & D over 4 years ago in reply to Charles Tsai

Intellectual 560 points

HI,

I need USB For data , ADC for some analog signal Monitoring and SPI for other peripheral communication. But withought ADC and SPI, just logging ethernet data receive is still slow, My another question is any interrupt service on each ethernet packet reception (Like aADC), what i feel is main loop executing slow.

Presently i have just connected one client in future 25 client has to be connected with this server and at the same speed of all client data is to be logged to USB drive, any way I can remove ADC to other MCU

REgards

Khodidas

0 Charles Tsai over 4 years ago in reply to R & D

TI__Guru**** 191906 points

Hi,

Can you increase both the send and receive buffer size and see if that makes a difference?

0 R & D over 4 years ago in reply to Charles Tsai

Intellectual 560 points

I tried this already, doesnt make a difference, as my transmit payload size is of 4 Bytes.

0 Charles Tsai over 4 years ago in reply to R & D

TI__Guru**** 191906 points

I don't think you are making the best efficiency use of the network bandwidth. A maximum ethernet frame is about 1518 bytes with 64 bytes of overhead. In your case, you have 4 bytes of payload and 64 bytes of overhead (TCP header, IP header and Ethernet header). I'm not surprised you are achieving low bandwidth. For experiment, why don't you increase your payload size, perhaps to maximum payload and what would you measure?

Also see the below two articles that will help on bandwidth efficiency.

https://packetpushers.net/tcp-over-ip-bandwidth-overhead/#:~:text=over%20the%20network-,Summary,bandwidth%20overhead%20is%20approximately%202.8%25.

https://searchnetworking.techtarget.com/answer/Minimum-and-maximum-Ethernet-frame-sizes#:~:text=The%20original%20Ethernet%20IEEE%20802.3,ICMP%20packet%20is%2074%20bytes.

0 R & D over 4 years ago in reply to Charles Tsai

Intellectual 560 points

Actually Requirement of client for sending several parameter data at particular interval among them two ADC data has to be send at rate of 1MSPS. The data is of 4 HEX Bytes in which 1st is device id, 2nd is parameter id, and 3&4th is parameter value. If I modify the data and send all data then also payload is not more than 50 Bytes. So, from client side I achieved speed up to 3.2Mbps max, but at same rate server is not able to receive as it does by polling. Still I will do more possible iterations of different payload size

Til this if you have any suggestion, then revert back.

Thank You

Regards

Khodidas

0 Charles Tsai over 4 years ago in reply to R & D

TI__Guru**** 191906 points

HI,

R & D said:
but at same rate server is not able to receive as it does by polling.

What do you mean the server is doing polling. What does the server poll?

Talking about interrupt, I think it is very dangerous the way you register interrupt for the ADC in the below code snippet. You can corrupt the vector table that is managed by the OS kernel. See this post for explanation. https://e2e.ti.com/support/microcontrollers/other/f/other-microcontrollers-forum/849627/faq-can-i-update-the-vector-table-with-intregister-when-using-ti-rtos?tisearch=e2e-sitesearch&keymatch=faq%3Atrue

// ADC0SS0 Interrupt source
ADCIntRegister(ADC0_BASE, 0, ADC0IntHandler);

// Register Interrupt to NVIC
IntRegister(INT_ADC0SS0, ADC0IntHandler);

0 R & D over 4 years ago in reply to Charles Tsai

Intellectual 560 points

Finally, I came to a solution regarding sampling rate of ADC and transfer rate on Ethernet , during working on another similar application. i came to a conclusion that my requirements will get fulfilled easily for ADC Sampling rate as well as Ethernet transfer speed requirement. so from my end I am closing this question. I further any query, then i will start with new question.

Thank you So much for support,

Regards

Khodidas

Arm-based microcontrollers

Arm-based microcontrollers forum

EK-TM4C1294XL: Ethernet recieve speed.
