AM67: AM67x work with DSI to HDMI bridge

Rich Chen

Part Number: AM67
Other Parts Discussed in Thread: AB15

Tool/software:

Dear champ,

My customer is working on AM67x platform with Lontium LT9611UXD which is DSI to HDMI bridge.

Lontium provide a driver (file.zip) and dts file https://e2e.ti.com/cfs-file/__key/communityserver-discussions-components-files/791/lontium_5F00_lt9611ex.dts0880.file.zip

TIDSS driver can be loaded normally but DSI has no signal output.

There is no output from LT9611UXD either.

Here is the demsg log below.

Fullscreen lt9611ex_dmesg_out.log Download

[    0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034]
[    0.000000] Linux version 6.12.24-rt (user@ubuntu) (aarch64-none-linux-gnu-gcc (Arm GNU Toolchain 11.3.Rel1) 11.3.1 20220712, GNU ld (Arm GNU Toolchain 11.3.Rel1) 2.38.20220708) #16 SMP PREEMPT_RT Mon Jun 23 14:37:39 CST 2025
[    0.000000] Machine model: Texas Instruments J722S ECU1270
[    0.000000] efi: UEFI not found.
[    0.000000] Reserved memory: created CMA memory pool at 0x00000008c8000000, size 896 MiB
[    0.000000] OF: reserved mem: initialized node linux,cma, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000008c8000000..0x00000008ffffffff (917504 KiB) map reusable linux,cma
[    0.000000] OF: reserved mem: 0x000000009e800000..0x000000009fffffff (24576 KiB) nomap non-reusable optee@9e800000
[    0.000000] OF: reserved mem: 0x0000000080000000..0x000000008007ffff (512 KiB) nomap non-reusable tfa@80000000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a0000000, size 1 MiB
[    0.000000] OF: reserved mem: initialized node r5f-dma-memory@a0000000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a0000000..0x00000000a00fffff (1024 KiB) nomap non-reusable r5f-dma-memory@a0000000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a0100000, size 15 MiB
[    0.000000] OF: reserved mem: initialized node r5f-memory@a0100000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a0100000..0x00000000a0ffffff (15360 KiB) nomap non-reusable r5f-memory@a0100000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a1000000, size 1 MiB
[    0.000000] OF: reserved mem: initialized node mcu-r5fss-dma-memory-region@a1000000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a1000000..0x00000000a10fffff (1024 KiB) nomap non-reusable mcu-r5fss-dma-memory-region@a1000000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a1100000, size 15 MiB
[    0.000000] OF: reserved mem: initialized node mcu-r5fss-memory-region@a1100000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a1100000..0x00000000a1ffffff (15360 KiB) nomap non-reusable mcu-r5fss-memory-region@a1100000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a2000000, size 1 MiB
[    0.000000] OF: reserved mem: initialized node main-r5fss-dma-memory-region@a2000000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a2000000..0x00000000a20fffff (1024 KiB) nomap non-reusable main-r5fss-dma-memory-region@a2000000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a2100000, size 15 MiB
[    0.000000] OF: reserved mem: initialized node main-r5fss-memory-region@a2100000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a2100000..0x00000000a2ffffff (15360 KiB) nomap non-reusable main-r5fss-memory-region@a2100000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a3000000, size 1 MiB
[    0.000000] OF: reserved mem: initialized node c7x-dma-memory@a3000000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a3000000..0x00000000a30fffff (1024 KiB) nomap non-reusable c7x-dma-memory@a3000000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a3100000, size 15 MiB
[    0.000000] OF: reserved mem: initialized node c7x-memory@a3100000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a3100000..0x00000000a3ffffff (15360 KiB) nomap non-reusable c7x-memory@a3100000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a4000000, size 1 MiB
[    0.000000] OF: reserved mem: initialized node c7x-dma-memory@a4000000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a4000000..0x00000000a40fffff (1024 KiB) nomap non-reusable c7x-dma-memory@a4000000
[    0.000000] Reserved memory: created DMA memory pool at 0x00000000a4100000, size 15 MiB
[    0.000000] OF: reserved mem: initialized node c7x-memory@a4100000, compatible id shared-dma-pool
[    0.000000] OF: reserved mem: 0x00000000a4100000..0x00000000a4ffffff (15360 KiB) nomap non-reusable c7x-memory@a4100000
[    0.000000] OF: reserved mem: 0x00000000a5000000..0x00000000a57fffff (8192 KiB) nomap non-reusable ipc-memories@a5000000
[    0.000000] Zone ranges:
[    0.000000]   DMA      [mem 0x0000000080000000-0x00000000ffffffff]
[    0.000000]   DMA32    empty
[    0.000000]   Normal   [mem 0x0000000100000000-0x00000008ffffffff]
[    0.000000] Movable zone start for each node
[    0.000000] Early memory node ranges
[    0.000000]   node   0: [mem 0x0000000080000000-0x000000008007ffff]
[    0.000000]   node   0: [mem 0x0000000080080000-0x000000009e7fffff]
[    0.000000]   node   0: [mem 0x000000009e800000-0x00000000a57fffff]
[    0.000000]   node   0: [mem 0x00000000a5800000-0x00000000ffffffff]
[    0.000000]   node   0: [mem 0x0000000880000000-0x00000008ffffffff]
[    0.000000] Initmem setup node 0 [mem 0x0000000080000000-0x00000008ffffffff]
[    0.000000] psci: probing for conduit method from DT.
[    0.000000] psci: PSCIv1.1 detected in firmware.
[    0.000000] psci: Using standard PSCI v0.2 function IDs
[    0.000000] psci: Trusted OS migration not required
[    0.000000] psci: SMC Calling Convention v1.5
[    0.000000] percpu: Embedded 23 pages/cpu s54768 r8192 d31248 u94208
[    0.000000] pcpu-alloc: s54768 r8192 d31248 u94208 alloc=23*4096
[    0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3
[    0.000000] Detected VIPT I-cache on CPU0
[    0.000000] CPU features: detected: GIC system register CPU interface
[    0.000000] CPU features: kernel page table isolation disabled by kernel configuration
[    0.000000] CPU features: detected: ARM erratum 845719
[    0.000000] alternatives: applying boot alternatives
[    0.000000] Kernel command line: console=ttyS2,115200n8 root=/dev/mmcblk0p2 rw rootfstype=ext4 rootwait video=HDMA-A-1:1920x1080M@60
[    0.000000] Dentry cache hash table entries: 524288 (order: 10, 4194304 bytes, linear)
[    0.000000] Inode-cache hash table entries: 262144 (order: 9, 2097152 bytes, linear)
[    0.000000] Built 1 zonelists, mobility grouping on.  Total pages: 1048576
[    0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[    0.000000] software IO TLB: area num 4.
[    0.000000] software IO TLB: mapped [mem 0x00000000fbfff000-0x00000000fffff000] (64MB)
[    0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[    0.000000] rcu: Preemptible hierarchical RCU implementation.
[    0.000000] rcu: 	RCU restricting CPUs from NR_CPUS=512 to nr_cpu_ids=4.
[    0.000000] rcu: 	RCU_SOFTIRQ processing moved to rcuc kthreads.
[    0.000000] 	No expedited grace period (rcu_normal_after_boot).
[    0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 100 jiffies.
[    0.000000] rcu: Adjusting geometry for rcu_fanout_leaf=16, nr_cpu_ids=4
[    0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[    0.000000] GICv3: GIC: Using split EOI/Deactivate mode
[    0.000000] GICv3: 256 SPIs implemented
[    0.000000] GICv3: 0 Extended SPIs implemented
[    0.000000] Root IRQ handler: 0xffff8000800100c0
[    0.000000] GICv3: GICv3 features: 16 PPIs
[    0.000000] GICv3: GICD_CTRL.DS=0, SCR_EL3.FIQ=1
[    0.000000] GICv3: CPU0: found redistributor 0 region 0:0x0000000001880000
[    0.000000] ITS [mem 0x01820000-0x0182ffff]
[    0.000000] GIC: enabling workaround for ITS: Socionext Synquacer pre-ITS
[    0.000000] ITS@0x0000000001820000: Devices Table too large, reduce ids 20->19
[    0.000000] ITS@0x0000000001820000: allocated 524288 Devices @880800000 (flat, esz 8, psz 64K, shr 0)
[    0.000000] ITS: using cache flushing for cmd queue
[    0.000000] GICv3: using LPI property table @0x0000000880040000
[    0.000000] GIC: using cache flushing for LPI property table
[    0.000000] GICv3: CPU0: using allocated LPI pending table @0x0000000880050000
[    0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention.
[    0.000000] arch_timer: cp15 timer(s) running at 200.00MHz (phys).
[    0.000000] clocksource: arch_sys_counter: mask: 0x3ffffffffffffff max_cycles: 0x2e2049d3e8, max_idle_ns: 440795210634 ns
[    0.000000] sched_clock: 58 bits at 200MHz, resolution 5ns, wraps every 4398046511102ns
[    0.000315] Console: colour dummy device 80x25
[    0.000370] Calibrating delay loop (skipped), value calculated using timer frequency.. 400.00 BogoMIPS (lpj=200000)
[    0.000380] pid_max: default: 32768 minimum: 301
[    0.000440] LSM: initializing lsm=capability
[    0.000564] Mount-cache hash table entries: 8192 (order: 4, 65536 bytes, linear)
[    0.000582] Mountpoint-cache hash table entries: 8192 (order: 4, 65536 bytes, linear)
[    0.007028] rcu: Hierarchical SRCU implementation.
[    0.007035] rcu: 	Max phase no-delay instances is 400.
[    0.008065] Timer migration: 1 hierarchy levels; 8 children per group; 1 crossnode level
[    0.009109] EFI services will not be available.
[    0.009230] smp: Bringing up secondary CPUs ...
[    0.014293] Detected VIPT I-cache on CPU1
[    0.014369] GICv3: CPU1: found redistributor 1 region 0:0x00000000018a0000
[    0.014385] GICv3: CPU1: using allocated LPI pending table @0x0000000880060000
[    0.014429] CPU1: Booted secondary processor 0x0000000001 [0x410fd034]
[    0.018335] Detected VIPT I-cache on CPU2
[    0.018390] GICv3: CPU2: found redistributor 2 region 0:0x00000000018c0000
[    0.018404] GICv3: CPU2: using allocated LPI pending table @0x0000000880070000
[    0.018434] CPU2: Booted secondary processor 0x0000000002 [0x410fd034]
[    0.022307] Detected VIPT I-cache on CPU3
[    0.022360] GICv3: CPU3: found redistributor 3 region 0:0x00000000018e0000
[    0.022373] GICv3: CPU3: using allocated LPI pending table @0x0000000880080000
[    0.022401] CPU3: Booted secondary processor 0x0000000003 [0x410fd034]
[    0.022514] smp: Brought up 1 node, 4 CPUs
[    0.022519] SMP: Total of 4 processors activated.
[    0.022522] CPU: All CPU(s) started at EL2
[    0.022525] CPU features: detected: 32-bit EL0 Support
[    0.022529] CPU features: detected: CRC32 instructions
[    0.022560] alternatives: applying system-wide alternatives
[    0.022930] Memory: 2996148K/4194304K available (10944K kernel code, 1196K rwdata, 2868K rodata, 2432K init, 654K bss, 272260K reserved, 917504K cma-reserved)
[    0.023881] devtmpfs: initialized
[    0.035652] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 1911260446275000 ns
[    0.035672] futex hash table entries: 1024 (order: 4, 65536 bytes, linear)
[    0.061065] 28192 pages in range for non-PLT usage
[    0.061081] 519712 pages in range for PLT usage
[    0.061303] pinctrl core: initialized pinctrl subsystem
[    0.061867] DMI not present or invalid.
[    0.062415] NET: Registered PF_NETLINK/PF_ROUTE protocol family
[    0.063538] DMA: preallocated 512 KiB GFP_KERNEL pool for atomic allocations
[    0.063611] DMA: preallocated 512 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations
[    0.063687] DMA: preallocated 512 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations
[    0.063751] audit: initializing netlink subsys (disabled)
[    0.063911] audit: type=2000 audit(0.063:1): state=initialized audit_enabled=0 res=1
[    0.064417] thermal_sys: Registered thermal governor 'step_wise'
[    0.064600] ASID allocator initialised with 65536 entries
[    0.068840] /bus@f0000/interrupt-controller@1800000: Fixed dependency cycle(s) with /bus@f0000/interrupt-controller@1800000
[    0.068981] /bus@f0000/i2c@20000000/hdmi-bridge@41: Fixed dependency cycle(s) with /bus@f0000/dsi@30500000
[    0.069127] /bus@f0000/dss@30220000: Fixed dependency cycle(s) with /bus@f0000/dsi@30500000
[    0.069146] /bus@f0000/dsi@30500000: Fixed dependency cycle(s) with /bus@f0000/dss@30220000
[    0.069157] /bus@f0000/dsi@30500000: Fixed dependency cycle(s) with /bus@f0000/i2c@20000000/hdmi-bridge@41
[    0.075325] /bus@f0000/i2c@20000000/hdmi-bridge@41: Fixed dependency cycle(s) with /bus@f0000/dsi@30500000
[    0.078447] /bus@f0000/dss@30220000: Fixed dependency cycle(s) with /bus@f0000/dsi@30500000
[    0.078671] /bus@f0000/dss@30220000: Fixed dependency cycle(s) with /bus@f0000/dsi@30500000
[    0.078737] /bus@f0000/i2c@20000000/hdmi-bridge@41: Fixed dependency cycle(s) with /bus@f0000/dsi@30500000
[    0.078797] /bus@f0000/dsi@30500000: Fixed dependency cycle(s) with /bus@f0000/dss@30220000
[    0.078867] /bus@f0000/dsi@30500000: Fixed dependency cycle(s) with /bus@f0000/i2c@20000000/hdmi-bridge@41
[    0.081760] /bus@f0000/i2c@20000000/hdmi-bridge@41: Fixed dependency cycle(s) with /hdmi-out
[    0.081861] /hdmi-out: Fixed dependency cycle(s) with /bus@f0000/i2c@20000000/hdmi-bridge@41
[    0.082602] HugeTLB: registered 1.00 GiB page size, pre-allocated 0 pages
[    0.082611] HugeTLB: 0 KiB vmemmap can be freed for a 1.00 GiB page
[    0.082615] HugeTLB: registered 32.0 MiB page size, pre-allocated 0 pages
[    0.082618] HugeTLB: 0 KiB vmemmap can be freed for a 32.0 MiB page
[    0.082622] HugeTLB: registered 2.00 MiB page size, pre-allocated 0 pages
[    0.082624] HugeTLB: 0 KiB vmemmap can be freed for a 2.00 MiB page
[    0.082628] HugeTLB: registered 64.0 KiB page size, pre-allocated 0 pages
[    0.082630] HugeTLB: 0 KiB vmemmap can be freed for a 64.0 KiB page
[    0.083906] k3-chipinfo 43000014.chipid: Family:J722S rev:SR1.0 JTAGID[0x0bba002f] Detected
[    0.084689] iommu: Default domain type: Translated
[    0.084698] iommu: DMA domain TLB invalidation policy: strict mode
[    0.086280] SCSI subsystem initialized
[    0.087771] libata version 3.00 loaded.
[    0.087999] usbcore: registered new interface driver usbfs
[    0.088028] usbcore: registered new interface driver hub
[    0.088067] usbcore: registered new device driver usb
[    0.088641] pps_core: LinuxPPS API ver. 1 registered
[    0.088645] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it>
[    0.088658] PTP clock support registered
[    0.088689] EDAC MC: Ver: 3.0.0
[    0.089019] scmi_core: SCMI protocol bus registered
[    0.089309] FPGA manager framework
[    0.089409] Advanced Linux Sound Architecture Driver Initialized.
[    0.090569] vgaarb: loaded
[    0.090891] clocksource: Switched to clocksource arch_sys_counter
[    0.091118] VFS: Disk quotas dquot_6.6.0
[    0.091137] VFS: Dquot-cache hash table entries: 512 (order 0, 4096 bytes)
[    0.098082] NET: Registered PF_INET protocol family
[    0.098278] IP idents hash table entries: 65536 (order: 7, 524288 bytes, linear)
[    0.100859] tcp_listen_portaddr_hash hash table entries: 2048 (order: 4, 81920 bytes, linear)
[    0.100966] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear)
[    0.100979] TCP established hash table entries: 32768 (order: 6, 262144 bytes, linear)
[    0.101386] TCP bind hash table entries: 32768 (order: 9, 2621440 bytes, linear)
[    0.103402] TCP: Hash tables configured (established 32768 bind 32768)
[    0.103562] UDP hash table entries: 2048 (order: 5, 196608 bytes, linear)
[    0.103717] UDP-Lite hash table entries: 2048 (order: 5, 196608 bytes, linear)
[    0.104073] NET: Registered PF_UNIX/PF_LOCAL protocol family
[    0.104508] RPC: Registered named UNIX socket transport module.
[    0.104513] RPC: Registered udp transport module.
[    0.104516] RPC: Registered tcp transport module.
[    0.104518] RPC: Registered tcp-with-tls transport module.
[    0.104521] RPC: Registered tcp NFSv4.1 backchannel transport module.
[    0.104534] PCI: CLS 0 bytes, default 64
[    0.105600] Initialise system trusted keyrings
[    0.105771] workingset: timestamp_bits=62 max_order=20 bucket_order=0
[    0.106116] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[    0.106341] NFS: Registering the id_resolver key type
[    0.106370] Key type id_resolver registered
[    0.106373] Key type id_legacy registered
[    0.106392] nfs4filelayout_init: NFSv4 File Layout Driver Registering...
[    0.106397] nfs4flexfilelayout_init: NFSv4 Flexfile Layout Driver Registering...
[    0.151730] Key type asymmetric registered
[    0.151739] Asymmetric key parser 'x509' registered
[    0.151805] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 244)
[    0.151810] io scheduler mq-deadline registered
[    0.151814] io scheduler kyber registered
[    0.151835] io scheduler bfq registered
[    0.155274] pinctrl-single 4084000.pinctrl: 34 pins, size 136
[    0.155983] pinctrl-single f4000.pinctrl: 171 pins, size 684
[    0.164552] Serial: 8250/16550 driver, 12 ports, IRQ sharing enabled
[    0.169603] adv_board: Registerered
[    0.177630] brd: module loaded
[    0.183169] loop: module loaded
[    0.184324] megasas: 07.727.03.00-rc1
[    0.188863] tun: Universal TUN/TAP device driver, 1.6
[    0.189541] PPP generic driver version 2.4.2
[    0.189695] PPP BSD Compression module registered
[    0.189700] PPP Deflate Compression module registered
[    0.189728] PPP MPPE Compression module registered
[    0.189733] NET: Registered PF_PPPOX protocol family
[    0.189759] SLIP: version 0.8.4-NET3.019-NEWTTY (dynamic channels, max=256).
[    0.189763] CSLIP: code copyright 1989 Regents of the University of California.
[    0.190076] VFIO - User Level meta-driver version: 0.3
[    0.191417] usbcore: registered new interface driver usb-storage
[    0.192109] i2c_dev: i2c /dev entries driver
[    0.192770] sdhci: Secure Digital Host Controller Interface driver
[    0.192773] sdhci: Copyright(c) Pierre Ossman
[    0.193029] sdhci-pltfm: SDHCI platform and OF driver helper
[    0.193727] SMCCC: SOC_ID: ARCH_SOC_ID not implemented, skipping ....
[    0.194444] usbcore: registered new interface driver usbhid
[    0.194448] usbhid: USB HID core driver
[    0.195331] optee: probing for conduit method.
[    0.195360] optee: revision 4.5 (ef1ebdc23034a804)
[    0.195711] optee: dynamic shared memory is enabled
[    0.196352] optee: initialized driver
[    0.196448] random: crng init done
[    0.198321] Initializing XFRM netlink socket
[    0.198354] NET: Registered PF_PACKET protocol family
[    0.198428] Key type dns_resolver registered
[    0.207972] Loading compiled-in X.509 certificates
[    0.221097] ti-sci 44043000.system-controller: ABI: 4.0 (firmware rev 0x000b '11.0.9--v11.00.09+ (Fancy Rat)')
[    0.279699] omap_i2c 2b200000.i2c: bus 1 rev0.12 at 400 kHz
[    0.280582] /hdmi-out: Fixed dependency cycle(s) with /bus@f0000/i2c@20000000/hdmi-bridge@41
[    0.280660] /bus@f0000/dsi@30500000: Fixed dependency cycle(s) with /bus@f0000/i2c@20000000/hdmi-bridge@41
[    0.280788] /bus@f0000/i2c@20000000/hdmi-bridge@41: Fixed dependency cycle(s) with /hdmi-out
[    0.280852] /bus@f0000/i2c@20000000/hdmi-bridge@41: Fixed dependency cycle(s) with /bus@f0000/dsi@30500000
[    0.281210] omap_i2c 20000000.i2c: bus 0 rev0.12 at 400 kHz
[    0.305105] tpm_tis_i2c 3-002e: 2.0 TPM (device-id 0x0, rev-id 78)
[    0.348727] rtc-s35390a 3-0030: registered as rtc0
[    0.349025] rtc-s35390a 3-0030: setting system clock to 2025-06-24T07:21:57 UTC (1750749717)
[    0.349222] omap_i2c 20030000.i2c: bus 3 rev0.12 at 400 kHz
[    0.349442] ti-sci-intr 4210000.interrupt-controller: Interrupt Router 5 domain created
[    0.349578] ti-sci-intr bus@f0000:interrupt-controller@a00000: Interrupt Router 3 domain created
[    0.349804] ti-sci-inta 48000000.interrupt-controller: Interrupt Aggregator domain 28 created
[    0.350092] ti-sci-inta 4e400000.interrupt-controller: Interrupt Aggregator domain 200 created
[    0.356222] ti-udma 485c0100.dma-controller: Number of rings: 82
[    0.359030] ti-udma 485c0100.dma-controller: Channels: 44 (bchan: 16, tchan: 12, rchan: 16)
[    0.361803] ti-udma 485c0000.dma-controller: Number of rings: 150
[    0.367348] ti-udma 485c0000.dma-controller: Channels: 35 (tchan: 20, rchan: 15)
[    0.369636] ti-udma 4e230000.dma-controller: Number of rings: 40
[    0.372759] ti-udma 4e230000.dma-controller: Channels: 40 (bchan: 0, tchan: 8, rchan: 32)
[    0.376096] printk: legacy console [ttyS2] disabled
[    0.376443] 2800000.serial: ttyS2 at MMIO 0x2800000 (irq = 308, base_baud = 3000000) is a 8250
[    0.376516] printk: legacy console [ttyS2] enabled
[    0.417901] davinci_mdio 8000f00.mdio: davinci mdio revision 17.7, bus freq 1000000
[    0.424734] davinci_mdio 8000f00.mdio: phy[0]: device 8000f00.mdio:00, driver TI DP83867
[    0.424745] davinci_mdio 8000f00.mdio: phy[9]: device 8000f00.mdio:09, driver TI DP83867
[    0.424783] am65-cpsw-nuss 8000000.ethernet: initializing am65 cpsw nuss version 0x6BA01903, cpsw version 0x6BA81903 Ports: 3 quirks:00000006
[    0.425708] am65-cpsw-nuss 8000000.ethernet: initialized cpsw ale version 1.5
[    0.425717] am65-cpsw-nuss 8000000.ethernet: ALE Table size 512, Policers 32
[    0.426367] am65-cpsw-nuss 8000000.ethernet: CPTS ver 0x4e8a010d, freq:500000000, add_val:1 pps:0
[    0.581312] am65-cpsw-nuss 8000000.ethernet: set new flow-id-base 19
[    0.587092] xhci-hcd xhci-hcd.0.auto: xHCI Host Controller
[    0.587119] xhci-hcd xhci-hcd.0.auto: new USB bus registered, assigned bus number 1
[    0.587240] xhci-hcd xhci-hcd.0.auto: USB3 root hub has no ports
[    0.587246] xhci-hcd xhci-hcd.0.auto: hcc params 0x0258fe6d hci version 0x110 quirks 0x0000808020000010
[    0.587442] xhci-hcd xhci-hcd.0.auto: irq 319, io mem 0x31000000
[    0.588213] hub 1-0:1.0: USB hub found
[    0.588239] hub 1-0:1.0: 1 port detected
[    0.590470] mmc0: CQHCI version 5.10
[    0.604504] j721e-pcie f102000.pcie: host bridge /bus@f0000/pcie@f102000 ranges:
[    0.604547] j721e-pcie f102000.pcie:       IO 0x0600001000..0x0600100fff -> 0x0000001000
[    0.604566] j721e-pcie f102000.pcie:      MEM 0x0600101000..0x06ffffffff -> 0x0000101000
[    0.604581] j721e-pcie f102000.pcie:   IB MEM 0x0000000000..0xffffffffffff -> 0x0000000000
[    0.637893] mmc0: SDHCI controller on fa10000.mmc [fa10000.mmc] using ADMA 64-bit
[    0.725859] mmc0: Command Queue Engine enabled
[    0.725910] mmc0: new HS200 MMC card at address 0001
[    0.726621] mmcblk0: mmc0:0001 C9A551 29.1 GiB
[    0.728296]  mmcblk0: p1 p2 p3 p4
[    0.729099] mmcblk0boot0: mmc0:0001 C9A551 4.00 MiB
[    0.730189] mmcblk0boot1: mmc0:0001 C9A551 4.00 MiB
[    0.731325] mmcblk0rpmb: mmc0:0001 C9A551 16.0 MiB, chardev (239:0)
[    0.825908] usb 1-1: new high-speed USB device number 2 using xhci-hcd
[    1.003769] hub 1-1:1.0: USB hub found
[    1.003821] hub 1-1:1.0: 4 ports detected
[    1.709080] j721e-pcie f102000.pcie: PCI host bridge to bus 0000:00
[    1.709099] pci_bus 0000:00: root bus resource [bus 00-ff]
[    1.709109] pci_bus 0000:00: root bus resource [io  0x0000-0xfffff] (bus address [0x1000-0x100fff])
[    1.709117] pci_bus 0000:00: root bus resource [mem 0x600101000-0x6ffffffff] (bus address [0x00101000-0xffffffff])
[    1.709151] pci 0000:00:00.0: [104c:b010] type 01 class 0x060400 PCIe Root Port
[    1.709170] pci 0000:00:00.0: PCI bridge to [bus 00]
[    1.709178] pci 0000:00:00.0:   bridge window [io  0x0000-0x0fff]
[    1.709184] pci 0000:00:00.0:   bridge window [mem 0x00000000-0x000fffff]
[    1.709193] pci 0000:00:00.0:   bridge window [mem 0x00000000-0x000fffff 64bit pref]
[    1.709252] pci 0000:00:00.0: supports D1
[    1.709257] pci 0000:00:00.0: PME# supported from D0 D1 D3hot
[    1.711165] pci 0000:00:00.0: bridge configuration invalid ([bus 00-00]), reconfiguring
[    1.711313] pci_bus 0000:01: busn_res: [bus 01-ff] end is updated to 01
[    1.711335] pci 0000:00:00.0: PCI bridge to [bus 01]
[    1.711344] pci_bus 0000:00: resource 4 [io  0x0000-0xfffff]
[    1.711350] pci_bus 0000:00: resource 5 [mem 0x600101000-0x6ffffffff]
[    1.711467] pcieport 0000:00:00.0: of_irq_parse_pci: failed with rc=-22
[    1.711978] pcieport 0000:00:00.0: PME: Signaling with IRQ 493
[    1.712252] pcieport 0000:00:00.0: AER: enabled with IRQ 493
[    1.713826] 2810000.serial: ttyS3 at MMIO 0x2810000 (irq = 494, base_baud = 3000000) is a 8250
[    1.715452] 2820000.serial: ttyS4 at MMIO 0x2820000 (irq = 495, base_baud = 3000000) is a 8250
[    1.716980] 2830000.serial: ttyS5 at MMIO 0x2830000 (irq = 496, base_baud = 3000000) is a 8250
[    1.718476] 2840000.serial: ttyS6 at MMIO 0x2840000 (irq = 497, base_baud = 3000000) is a 8250
[    1.719944] 2850000.serial: ttyS7 at MMIO 0x2850000 (irq = 498, base_baud = 3000000) is a 8250
[    1.721478] 2860000.serial: ttyS8 at MMIO 0x2860000 (irq = 499, base_baud = 3000000) is a 8250
[    1.722010] +++ECU1270
                init.
[    1.722029] adv_board adv_board: board name: ECU1270
[    1.823327] sdhci-am654 fa00000.mmc: Got CD GPIO
[    1.823637] clk: Disabling unused clocks
[    1.824166] mmc1: CQHCI version 5.10
[    1.830677] PM: genpd: Disabling unused power domains
[    1.830853] ALSA device list:
[    1.830858]   No soundcards found.
[    1.877345] mmc1: SDHCI controller on fa00000.mmc [fa00000.mmc] using ADMA 64-bit
[    2.563913] EXT4-fs (mmcblk0p2): mounted filesystem bd8bf762-6251-4206-9c3c-b7729302cdb5 r/w with ordered data mode. Quota mode: none.
[    2.563988] VFS: Mounted root (ext4 filesystem) on device 179:2.
[    2.565646] devtmpfs: mounted
[    2.566402] Freeing unused kernel memory: 2432K
[    2.566515] Run /sbin/init as init process
[    2.566518]   with arguments:
[    2.566520]     /sbin/init
[    2.566522]   with environment:
[    2.566524]     HOME=/
[    2.566526]     TERM=linux
[    2.728296] NET: Registered PF_INET6 protocol family
[    2.729331] Segment Routing with IPv6
[    2.729370] In-situ OAM (IOAM) with IPv6
[    2.742500] systemd[1]: systemd 249.11-0ubuntu3.7 running in system mode (+PAM +AUDIT +SELINUX +APPARMOR +IMA +SMACK +SECCOMP +GCRYPT +GNUTLS +OPENSSL +ACL +BLKID +CURL +ELFUTILS +FIDO2 +IDN2 -IDN +IPTC +KMOD +LIBCRYPTSETUP +LIBFDISK +PCRE2 -PWQUALITY -P11KIT -QRENCODE +BZIP2 +LZ4 +XZ +ZLIB +ZSTD -XKBCOMMON +UTMP +SYSVINIT default-hierarchy=unified)
[    2.742983] systemd[1]: Detected architecture arm64.
[    2.786413] systemd[1]: Hostname set to <ecu1270-959a46>.
[    3.120054] systemd[1]: Queued start job for default target Graphical Interface.
[    3.122486] systemd[1]: Created slice Slice /system/getty.
[    3.141952] systemd[1]: Created slice Slice /system/modprobe.
[    3.155815] systemd[1]: Created slice Slice /system/serial-getty.
[    3.169764] systemd[1]: Created slice Slice /system/systemd-fsck.
[    3.183477] systemd[1]: Created slice User and Session Slice.
[    3.197209] systemd[1]: Started ntp-systemd-netif.path.
[    3.210253] systemd[1]: Started Dispatch Password Requests to Console Directory Watch.
[    3.228264] systemd[1]: Started Forward Password Requests to Wall Directory Watch.
[    3.245187] systemd[1]: Condition check resulted in Arbitrary Executable File Formats File System Automount Point being skipped.
[    3.245341] systemd[1]: Reached target Local Encrypted Volumes.
[    3.269606] systemd[1]: Reached target Path Units.
[    3.279932] systemd[1]: Reached target Remote File Systems.
[    3.293006] systemd[1]: Reached target Slice Units.
[    3.303532] systemd[1]: Reached target Swaps.
[    3.312999] systemd[1]: Reached target Local Verity Protected Volumes.
[    3.330143] systemd[1]: Listening on Syslog Socket.
[    3.341212] systemd[1]: Listening on fsck to fsckd communication Socket.
[    3.357274] systemd[1]: Listening on initctl Compatibility Named Pipe.
[    3.373748] systemd[1]: Listening on Journal Audit Socket.
[    3.387479] systemd[1]: Listening on Journal Socket (/dev/log).
[    3.401515] systemd[1]: Listening on Journal Socket.
[    3.412846] systemd[1]: Listening on Network Service Netlink Socket.
[    3.431522] systemd[1]: Listening on udev Control Socket.
[    3.444434] systemd[1]: Listening on udev Kernel Socket.
[    3.457056] systemd[1]: Reached target Socket Units.
[    3.487208] systemd[1]: Mounting Huge Pages File System...
[    3.500806] systemd[1]: Mounting POSIX Message Queue File System...
[    3.517757] systemd[1]: Mounting Kernel Debug File System...
[    3.531441] systemd[1]: Condition check resulted in Kernel Trace File System being skipped.
[    3.532205] systemd[1]: systemd-journald.service: unit configures an IP firewall, but the local system does not support BPF/cgroup firewalling.
[    3.532219] systemd[1]: (This warning is only shown for the first unit using IP firewalling.)
[    3.534487] systemd[1]: Starting Journal Service...
[    3.581430] systemd[1]: Starting Create List of Static Device Nodes...
[    3.598271] systemd[1]: Starting Load Kernel Module chromeos_pstore...
[    3.615370] systemd[1]: Starting Load Kernel Module configfs...
[    3.630427] systemd[1]: Starting Load Kernel Module drm...
[    3.645050] systemd[1]: Starting Load Kernel Module efi_pstore...
[    3.665645] systemd[1]: Starting Load Kernel Module fuse...
[    3.680466] systemd[1]: Starting Load Kernel Module pstore_blk...
[    3.681853] fuse: init (API version 7.41)
[    3.700143] systemd[1]: Starting Load Kernel Module pstore_zone...
[    3.732442] systemd[1]: Starting Load Kernel Module ramoops...
[    3.748333] systemd[1]: Starting Load Kernel Modules...
[    3.761875] systemd[1]: Starting Generate network units from Kernel command line...
[    3.781999] systemd[1]: Starting Remount Root and Kernel File Systems...
[    3.799087] systemd[1]: Starting Coldplug All udev Devices...
[    3.816060] systemd[1]: Started Journal Service.
[    4.052460] systemd-journald[152]: Received client request to flush runtime journal.
[    4.539015] CAN device driver interface
[    4.547036] fm25 spi0.0: 128 KByte fm25 fram, pagesize 4096
[    4.677994] omap-mailbox 29000000.mailbox: omap mailbox rev 0x66fca100
[    4.679742] omap-mailbox 29010000.mailbox: omap mailbox rev 0x66fca100
[    4.681307] omap-mailbox 29020000.mailbox: omap mailbox rev 0x66fca100
[    4.698112] omap-mailbox 29030000.mailbox: omap mailbox rev 0x66fca100
[    4.700712] at24 3-0050: supply vcc not found, using dummy regulator
[    4.705145] at24 3-0050: 256 byte 24c02 EEPROM, writable, 1 bytes/write
[    4.738493] lt9611ex 0-0041: Current version:0x0101
[    4.779327] mc: Linux media interface: v0.10
[    4.790174] k3-dsp-rproc 7e000000.dsp: assigned reserved memory node c7x-dma-memory@a3000000
[    4.790793] k3-dsp-rproc 7e000000.dsp: configured DSP for remoteproc mode
[    4.794437] remoteproc remoteproc0: 7e000000.dsp is available
[    4.804259] remoteproc remoteproc0: Direct firmware load for j722s-c71_0-fw failed with error -2
[    4.804286] remoteproc remoteproc0: powering up 7e000000.dsp
[    4.804324] remoteproc remoteproc0: Direct firmware load for j722s-c71_0-fw failed with error -2
[    4.804331] remoteproc remoteproc0: request_firmware failed: -2
[    4.812132] k3-dsp-rproc 7e200000.dsp: assigned reserved memory node c7x-dma-memory@a4000000
[    4.813984] k3-dsp-rproc 7e200000.dsp: configured DSP for remoteproc mode
[    4.833467] remoteproc remoteproc1: 7e200000.dsp is available
[    4.833688] remoteproc remoteproc1: Direct firmware load for j722s-c71_1-fw failed with error -2
[    4.833709] remoteproc remoteproc1: powering up 7e200000.dsp
[    4.833743] remoteproc remoteproc1: Direct firmware load for j722s-c71_1-fw failed with error -2
[    4.833751] remoteproc remoteproc1: request_firmware failed: -2
[    4.854341] videodev: Linux video capture interface: v2.00
[    4.873010] platform 79000000.r5f: configured R5F for remoteproc mode
[    4.873326] platform 79000000.r5f: assigned reserved memory node mcu-r5fss-dma-memory-region@a1000000
[    4.873823] remoteproc remoteproc2: 79000000.r5f is available
[    4.876088] remoteproc remoteproc2: Direct firmware load for j722s-mcu-r5f0_0-fw failed with error -2
[    4.876111] remoteproc remoteproc2: powering up 79000000.r5f
[    4.876144] remoteproc remoteproc2: Direct firmware load for j722s-mcu-r5f0_0-fw failed with error -2
[    4.876152] remoteproc remoteproc2: request_firmware failed: -2
[    4.903862] platform 78000000.r5f: R5F core may have been powered on by a different host, programmed state (0) != actual state (1)
[    4.904087] platform 78000000.r5f: configured R5F for IPC-only mode
[    4.904182] platform 78000000.r5f: assigned reserved memory node r5f-dma-memory@a0000000
[    4.908018] remoteproc remoteproc3: 78000000.r5f is available
[    4.908119] remoteproc remoteproc3: attaching to 78000000.r5f
[    4.926256] rproc-virtio rproc-virtio.1.auto: assigned reserved memory node r5f-dma-memory@a0000000
[    4.928647] virtio_rpmsg_bus virtio0: rpmsg host is online
[    4.928700] rproc-virtio rproc-virtio.1.auto: registered virtio0 (type 7)
[    4.928710] remoteproc remoteproc3: remote processor 78000000.r5f is now attached
[    4.928736] virtio_rpmsg_bus virtio0: creating channel ti.ipc4.ping-pong addr 0xd
[    4.928992] virtio_rpmsg_bus virtio0: creating channel rpmsg_chrdev addr 0xe
[    4.938116] platform 78400000.r5f: configured R5F for remoteproc mode
[    4.938520] platform 78400000.r5f: assigned reserved memory node main-r5fss-dma-memory-region@a2000000
[    4.944416] remoteproc remoteproc4: 78400000.r5f is available
[    4.944603] remoteproc remoteproc4: Direct firmware load for j722s-main-r5f0_0-fw failed with error -2
[    4.944623] remoteproc remoteproc4: powering up 78400000.r5f
[    4.944653] remoteproc remoteproc4: Direct firmware load for j722s-main-r5f0_0-fw failed with error -2
[    4.944661] remoteproc remoteproc4: request_firmware failed: -2
[    5.136731] lt9611ex 0-0041: lt9611ex_bridge_attach
[    5.154612] [drm] Initialized tidss 1.0.0 for 30220000.dss on minor 0
[    5.203992] lt9611ex 0-0041: .edid_read = lt9611ex_bridge_edid_read
[    5.204014] lt9611ex 0-0041: lt9611ex_get_edid_block block:0
[    5.204200] am65-cpsw-nuss 8000000.ethernet eth1: PHY [8000f00.mdio:09] driver [TI DP83867] (irq=POLL)
[    5.204219] am65-cpsw-nuss 8000000.ethernet eth1: configuring for phy/rgmii-rxid link mode
[    5.231283] lt9611ex 0-0041: EDID LEN: 256.
[    5.303818] am65-cpsw-nuss 8000000.ethernet eth0: PHY [8000f00.mdio:00] driver [TI DP83867] (irq=POLL)
[    5.303844] am65-cpsw-nuss 8000000.ethernet eth0: configuring for phy/rgmii-rxid link mode
[    5.426172] lt9611ex 0-0041: EDID data (256 bytes):

[    5.426194] 0x00,0xff,0xff,0xff,0xff,0xff,0xff,0x00,0x26,0x01,0x00,0x24,0x01,0x01,0x01,0x01,

[    5.426226] 0x07,0x20,0x01,0x03,0x80,0x34,0x1f,0x78,0x3e,0xee,0x91,0xa3,0x54,0x4c,0x99,0x26,

[    5.426252] 0x0f,0x50,0x54,0x21,0x08,0x00,0xd1,0xc0,0x01,0x01,0x01,0x01,0x01,0x01,0x01,0x01,

[    5.426278] 0x01,0x01,0x01,0x01,0x01,0x01,0x02,0x3a,0x80,0x18,0x71,0x38,0x2d,0x40,0x58,0x2c,

[    5.426306] 0x25,0x00,0x08,0x36,0x21,0x00,0x00,0x1e,0x00,0x00,0x00,0xfc,0x00,0x47,0x46,0x32,

[    5.426333] 0x34,0x30,0x0a,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x00,0x00,0x00,0xff,0x00,0x64,

[    5.426359] 0x65,0x6d,0x6f,0x73,0x65,0x74,0x2d,0x31,0x0a,0x20,0x30,0x20,0x00,0x00,0x00,0xfd,

[    5.426385] 0x00,0x32,0x91,0x1e,0xb4,0x24,0x00,0x0a,0x20,0x20,0x20,0x20,0x20,0x20,0x01,0xa5,

[    5.426413] 0x02,0x03,0x39,0xf2,0x4d,0x90,0x01,0x02,0x03,0x04,0x13,0x1f,0x20,0x21,0x22,0x3c,

[    5.426439] 0x3d,0x3e,0x23,0x09,0x7f,0x07,0x83,0x01,0x00,0x00,0x67,0x03,0x0c,0x00,0x10,0x00,

[    5.426465] 0x18,0x48,0xe2,0x00,0xd5,0xe3,0x05,0xc0,0x00,0xe6,0x06,0x05,0x01,0x69,0x69,0x4f,

[    5.426491] 0x68,0x1a,0x00,0x00,0x01,0x01,0x32,0x90,0xe6,0x5c,0x82,0x80,0x8c,0x70,0x38,0x2d,

[    5.426518] 0x40,0x30,0x20,0x3a,0x00,0x55,0x50,0x21,0x00,0x00,0x1e,0x8a,0x6f,0x80,0xa0,0x70,

[    5.426545] 0x38,0x40,0x40,0x30,0x20,0x25,0x00,0x55,0x50,0x21,0x00,0x00,0x1e,0x0e,0x5c,0x80,

[    5.426572] 0xa0,0x70,0x38,0x35,0x40,0x30,0x20,0x25,0x00,0x56,0x50,0x21,0x00,0x00,0x1e,0x00,

[    5.426599] 0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0xdb,

[    5.426637] lt9611ex 0-0041: lt9611ex_get_edid_block block:1
[    5.428680] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.428723] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 333 MB.
[    5.428749] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 285 MB.
[    5.428774] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 235 MB.
[    5.428800] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 39 MB.
[    5.428826] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 64 MB.
[    5.428833] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.428842] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.428850] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.428859] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.431650] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.431679] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.431690] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.431705] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 59 MB.
[    5.431719] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.431733] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.431743] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.431749] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 27 MB.
[    5.431755] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 27 MB.
[    5.431770] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.431784] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 59 MB.
[    5.431797] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.478157] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.479391] lt9611ex 0-0041: video info: h_total=2200, hactive=1920, hsync_len=44, hfront_porch=88, hback_porch=148
[    5.479412] lt9611ex 0-0041: video info: v_total=1125, vactive=1080, vsync_len=5, vfront_porch=2, vback_porch=38
[    5.479420] lt9611ex 0-0041: framerate=60
[    5.479424] lt9611ex 0-0041: vic = 0x00
[    5.496089] Console: switching to colour frame buffer device 240x67
[    5.536009] tidss 30220000.dss: [drm] fb0: tidssdrmfb frame buffer device
[    5.581933] m_can_platform 20711000.can: m_can device registered (irq=511, version=32)
[    5.591967] m_can_platform 20701000.can: m_can device registered (irq=512, version=32)
[    5.609998] lt9611ex 0-0041: .edid_read = lt9611ex_bridge_edid_read
[    5.610018] lt9611ex 0-0041: lt9611ex_get_edid_block block:0
[    5.645870] lt9611ex 0-0041: EDID LEN: 256.
[    5.831799] lt9611ex 0-0041: EDID data (256 bytes):

[    5.831824] 0x00,0xff,0xff,0xff,0xff,0xff,0xff,0x00,0x26,0x01,0x00,0x24,0x01,0x01,0x01,0x01,

[    5.831857] 0x07,0x20,0x01,0x03,0x80,0x34,0x1f,0x78,0x3e,0xee,0x91,0xa3,0x54,0x4c,0x99,0x26,

[    5.831986] 0x0f,0x50,0x54,0x21,0x08,0x00,0xd1,0xc0,0x01,0x01,0x01,0x01,0x01,0x01,0x01,0x01,

[    5.832014] 0x01,0x01,0x01,0x01,0x01,0x01,0x02,0x3a,0x80,0x18,0x71,0x38,0x2d,0x40,0x58,0x2c,

[    5.832041] 0x25,0x00,0x08,0x36,0x21,0x00,0x00,0x1e,0x00,0x00,0x00,0xfc,0x00,0x47,0x46,0x32,

[    5.832069] 0x34,0x30,0x0a,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x00,0x00,0x00,0xff,0x00,0x64,

[    5.832096] 0x65,0x6d,0x6f,0x73,0x65,0x74,0x2d,0x31,0x0a,0x20,0x30,0x20,0x00,0x00,0x00,0xfd,

[    5.832124] 0x00,0x32,0x91,0x1e,0xb4,0x24,0x00,0x0a,0x20,0x20,0x20,0x20,0x20,0x20,0x01,0xa5,

[    5.832151] 0x02,0x03,0x39,0xf2,0x4d,0x90,0x01,0x02,0x03,0x04,0x13,0x1f,0x20,0x21,0x22,0x3c,

[    5.832178] 0x3d,0x3e,0x23,0x09,0x7f,0x07,0x83,0x01,0x00,0x00,0x67,0x03,0x0c,0x00,0x10,0x00,

[    5.832205] 0x18,0x48,0xe2,0x00,0xd5,0xe3,0x05,0xc0,0x00,0xe6,0x06,0x05,0x01,0x69,0x69,0x4f,

[    5.832232] 0x68,0x1a,0x00,0x00,0x01,0x01,0x32,0x90,0xe6,0x5c,0x82,0x80,0x8c,0x70,0x38,0x2d,

[    5.832258] 0x40,0x30,0x20,0x3a,0x00,0x55,0x50,0x21,0x00,0x00,0x1e,0x8a,0x6f,0x80,0xa0,0x70,

[    5.832285] 0x38,0x40,0x40,0x30,0x20,0x25,0x00,0x55,0x50,0x21,0x00,0x00,0x1e,0x0e,0x5c,0x80,

[    5.832313] 0xa0,0x70,0x38,0x35,0x40,0x30,0x20,0x25,0x00,0x56,0x50,0x21,0x00,0x00,0x1e,0x00,

[    5.832339] 0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0xdb,

[    5.832378] lt9611ex 0-0041: lt9611ex_get_edid_block block:1
[    5.832802] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.832847] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 285 MB.
[    5.832874] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 235 MB.
[    5.833973] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.834007] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.834019] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[    5.834030] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834040] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834050] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834060] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834067] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834074] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834089] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834103] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834116] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[    5.834130] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 59 MB.
[    5.834143] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 59 MB.
[    5.834170] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 64 MB.
[    5.834196] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 39 MB.
[    5.834202] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 27 MB.
[    5.834208] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 27 MB.
[    5.834233] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 333 MB.
[    6.071185] xhci-hcd xhci-hcd.3.auto: xHCI Host Controller
[    6.072202] xhci-hcd xhci-hcd.3.auto: new USB bus registered, assigned bus number 2
[    6.072544] xhci-hcd xhci-hcd.3.auto: hcc params 0x200073c9 hci version 0x100 quirks 0x0000002000008010
[    6.075444] xhci-hcd xhci-hcd.3.auto: irq 513, io mem 0x31210000
[    6.075666] xhci-hcd xhci-hcd.3.auto: xHCI Host Controller
[    6.075690] xhci-hcd xhci-hcd.3.auto: new USB bus registered, assigned bus number 3
[    6.075710] xhci-hcd xhci-hcd.3.auto: Host supports USB 3.0 SuperSpeed
[    6.079694] hub 2-0:1.0: USB hub found
[    6.079747] hub 2-0:1.0: 1 port detected
[    6.080423] usb usb3: We don't know the algorithms for LPM for this host, disabling LPM.
[    6.093449] hub 3-0:1.0: USB hub found
[    6.093548] hub 3-0:1.0: 1 port detected
[    6.281701] EXT4-fs (mmcblk0p4): mounted filesystem ed6d50eb-42a2-4d78-9dea-1d1228c304c9 r/w with ordered data mode. Quota mode: none.
[    6.389388] EXT4-fs (mmcblk0p3): mounted filesystem 90f98fd8-7131-4eac-9c2d-cfd7952efd1e r/w with ordered data mode. Quota mode: none.
[    7.399355] am65-cpsw-nuss 8000000.ethernet eth0: Link is Up - 100Mbps/Full - flow control rx/tx
[   15.474908] lt9611ex 0-0041: .edid_read = lt9611ex_bridge_edid_read
[   15.474927] lt9611ex 0-0041: lt9611ex_get_edid_block block:0
[   15.485236] lt9611ex 0-0041: EDID LEN: 256.
[   15.623391] lt9611ex 0-0041: EDID data (256 bytes):

[   15.623413] 0x00,0xff,0xff,0xff,0xff,0xff,0xff,0x00,0x26,0x01,0x00,0x24,0x01,0x01,0x01,0x01,

[   15.623444] 0x07,0x20,0x01,0x03,0x80,0x34,0x1f,0x78,0x3e,0xee,0x91,0xa3,0x54,0x4c,0x99,0x26,

[   15.623470] 0x0f,0x50,0x54,0x21,0x08,0x00,0xd1,0xc0,0x01,0x01,0x01,0x01,0x01,0x01,0x01,0x01,

[   15.623497] 0x01,0x01,0x01,0x01,0x01,0x01,0x02,0x3a,0x80,0x18,0x71,0x38,0x2d,0x40,0x58,0x2c,

[   15.623523] 0x25,0x00,0x08,0x36,0x21,0x00,0x00,0x1e,0x00,0x00,0x00,0xfc,0x00,0x47,0x46,0x32,

[   15.623549] 0x34,0x30,0x0a,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x00,0x00,0x00,0xff,0x00,0x64,

[   15.623575] 0x65,0x6d,0x6f,0x73,0x65,0x74,0x2d,0x31,0x0a,0x20,0x30,0x20,0x00,0x00,0x00,0xfd,

[   15.623603] 0x00,0x32,0x91,0x1e,0xb4,0x24,0x00,0x0a,0x20,0x20,0x20,0x20,0x20,0x20,0x01,0xa5,

[   15.623629] 0x02,0x03,0x39,0xf2,0x4d,0x90,0x01,0x02,0x03,0x04,0x13,0x1f,0x20,0x21,0x22,0x3c,

[   15.623656] 0x3d,0x3e,0x23,0x09,0x7f,0x07,0x83,0x01,0x00,0x00,0x67,0x03,0x0c,0x00,0x10,0x00,

[   15.623682] 0x18,0x48,0xe2,0x00,0xd5,0xe3,0x05,0xc0,0x00,0xe6,0x06,0x05,0x01,0x69,0x69,0x4f,

[   15.623708] 0x68,0x1a,0x00,0x00,0x01,0x01,0x32,0x90,0xe6,0x5c,0x82,0x80,0x8c,0x70,0x38,0x2d,

[   15.623735] 0x40,0x30,0x20,0x3a,0x00,0x55,0x50,0x21,0x00,0x00,0x1e,0x8a,0x6f,0x80,0xa0,0x70,

[   15.623761] 0x38,0x40,0x40,0x30,0x20,0x25,0x00,0x55,0x50,0x21,0x00,0x00,0x1e,0x0e,0x5c,0x80,

[   15.623787] 0xa0,0x70,0x38,0x35,0x40,0x30,0x20,0x25,0x00,0x56,0x50,0x21,0x00,0x00,0x1e,0x00,

[   15.623813] 0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0xdb,

[   15.623850] lt9611ex 0-0041: lt9611ex_get_edid_block block:1
[   15.624312] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[   15.624356] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 285 MB.
[   15.624381] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 235 MB.
[   15.624389] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[   15.624396] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[   15.624405] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 148 MB.
[   15.624416] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624426] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624435] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624445] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624451] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624459] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624472] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624485] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624499] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 74 MB.
[   15.624511] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 59 MB.
[   15.624524] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 59 MB.
[   15.624549] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 64 MB.
[   15.624573] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 39 MB.
[   15.624579] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 27 MB.
[   15.624585] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 27 MB.
[   15.624610] lt9611ex 0-0041: lt9611ex_bridge_mode_valid Pixclk: 333 MB.
[   16.354942] platform 30210000.video-codec: deferred probe pending: (reason unknown)
[   16.354957] platform e0f0000.watchdog: deferred probe pending: (reason unknown)

Could you take a look which part may be missing for DSI to output signals?

BR, Rich

4 months ago

0 Takuma Fujiwara 4 months ago

TI__Guru 52873 points

Hi Rich,

Looks like framebuffer is created and EDID from monitor is obtained. Software-wise, it looks mostly set up.

Can you share the logs from the following commands:

kmsprint
modetest -M tidss

Regards,

Takuma

0 user5152479 4 months ago in reply to Takuma Fujiwara

Intellectual 525 points

root@ecu1270-959a46:~# kmsprint
Connector 0 (41) HDMI-A-1 (connected)
Encoder 0 (40) NONE
Crtc 0 (39) 1920x1080@60.00 148.500 1920/88/44/148/+ 1080/2/5/38/+ 60 (60.00) P|D
Plane 0 (32) fb-id: 50 (crtcs: 0) 0,0 1920x1080 -> 0,0 1920x1080 (AR12 RA12 RG16 BG16 AR15 AR24 AB24 RA24 BA24 RG24 BG24 AR30 AB30 XR12 RX12 XR15 XR24 XB24 RX24 BX24 XR30 XB30 YUYV UYVY NV12)
FB 50 1920x1080 XR24

root@ecu1270-959a46:~# modetest -M tidss
Encoders:
id crtc type possible crtcs possible clones
40 39 none 0x00000001 0x00000001

Connectors:
id encoder status name size (mm) modes encoders
41 40 connected HDMI-A-1 520x310 20 40
modes:
index name refresh (Hz) hdisp hss hse htot vdisp vss vse vtot
#0 1920x1080 60.00 1920 2008 2052 2200 1080 1082 1087 1125 148500 flags: phsync, pvsync; type: preferred, driver
#1 1920x1080 120.00 1920 1968 2000 2080 1080 1082 1087 1144 285540 flags: phsync, pvsync; type: driver
#2 1920x1080 100.00 1920 1968 2000 2080 1080 1082 1087 1133 235660 flags: phsync, pvsync; type: driver
#3 1920x1080 60.00 1920 2008 2052 2200 1080 1084 1089 1125 148500 flags: phsync, pvsync; type: driver
#4 1920x1080 59.94 1920 2008 2052 2200 1080 1084 1089 1125 148352 flags: phsync, pvsync; type: driver
#5 1920x1080 50.00 1920 2448 2492 2640 1080 1084 1089 1125 148500 flags: phsync, pvsync; type: driver
#6 1920x1080 30.00 1920 2008 2052 2200 1080 1084 1089 1125 74250 flags: phsync, pvsync; type: driver
#7 1920x1080 29.97 1920 2008 2052 2200 1080 1084 1089 1125 74176 flags: phsync, pvsync; type: driver
#8 1920x1080 25.00 1920 2448 2492 2640 1080 1084 1089 1125 74250 flags: phsync, pvsync; type: driver
#9 1920x1080 24.00 1920 2558 2602 2750 1080 1084 1089 1125 74250 flags: phsync, pvsync; type: driver
#10 1280x720 60.00 1280 1390 1430 1650 720 725 730 750 74250 flags: phsync, pvsync; type: driver
#11 1280x720 50.00 1280 1720 1760 1980 720 725 730 750 74250 flags: phsync, pvsync; type: driver
#12 1280x720 30.00 1280 3040 3080 3300 720 725 730 750 74250 flags: phsync, pvsync; type: driver
#13 1280x720 29.97 1280 3040 3080 3300 720 725 730 750 74176 flags: phsync, pvsync; type: driver
#14 1280x720 25.00 1280 3700 3740 3960 720 725 730 750 74250 flags: phsync, pvsync; type: driver
#15 1280x720 24.00 1280 3040 3080 3300 720 725 730 750 59400 flags: phsync, pvsync; type: driver
#16 1280x720 23.98 1280 3040 3080 3300 720 725 730 750 59341 flags: phsync, pvsync; type: driver
#17 1024x768 60.00 1024 1048 1184 1344 768 771 777 806 65000 flags: nhsync, nvsync; type: driver
#18 800x600 60.32 800 840 968 1056 600 601 605 628 40000 flags: phsync, pvsync; type: driver
#19 720x480 60.00 720 736 798 858 480 489 495 525 27027 flags: nhsync, nvsync; type: driver
props:
1 EDID:
flags: immutable blob
blobs:

value:
00ffffffffffff002601002401010101
0720010380341f783eee91a3544c9926
0f5054210800d1c00101010101010101
010101010101023a801871382d40582c
250008362100001e000000fc00474632
34300a20202020202020000000ff0064
656d6f7365742d310a203020000000fd
0032911eb424000a20202020202001a5
020339f24d9001020304131f2021223c
3d3e23097f078301000067030c001000
1848e200d5e305c000e606050169694f
681a000001013290e65c82808c70382d
4030203a0055502100001e8a6f80a070
3840403020250055502100001e0e5c80
a0703835403020250056502100001e00
000000000000000000000000000000db
2 DPMS:
flags: enum
enums: On=0 Standby=1 Suspend=2 Off=3
value: 0
5 link-status:
flags: enum
enums: Good=0 Bad=1
value: 0
6 non-desktop:
flags: immutable range
values: 0 1
value: 0
4 TILE:
flags: immutable blob
blobs:

value:

CRTCs:
id fb pos size
39 50 (0,0) (1920x1080)
#0 1920x1080 60.00 1920 2008 2052 2200 1080 1082 1087 1125 148500 flags: phsync, pvsync; type: preferred, driver
props:
24 VRR_ENABLED:
flags: range
values: 0 1
value: 0
27 CTM:
flags: blob
blobs:

value:
28 GAMMA_LUT:
flags: blob
blobs:

value:
29 GAMMA_LUT_SIZE:
flags: immutable range
values: 0 4294967295
value: 256

Planes:
id crtc fb CRTC x,y x,y gamma size possible crtcs
32 39 50 0,0 0,0 0 0x00000001
formats: AR12 AB12 RA12 RG16 BG16 AR15 AB15 AR24 AB24 RA24 BA24 RG24 BG24 AR30 AB30 XR12 XB12 RX12 XR15 XB15 XR24 XB24 RX24 BX24 XR30 XB30 YUYV UYVY NV12
props:
8 type:
flags: immutable enum
enums: Overlay=0 Primary=1 Cursor=2
value: 1
30 IN_FORMATS:
flags: immutable blob
blobs:

value:
01000000000000001d00000018000000
01000000900000004152313241423132
52413132524731364247313641523135
41423135415232344142323452413234
42413234524732344247323441523330
41423330585231325842313252583132
58523135584231355852323458423234
52583234425832345852333058423330
59555956555956594e56313200000000
ffffff1f000000000000000000000000
0000000000000000
in_formats blob decoded:
AR12: LINEAR
AB12: LINEAR
RA12: LINEAR
RG16: LINEAR
BG16: LINEAR
AR15: LINEAR
AB15: LINEAR
AR24: LINEAR
AB24: LINEAR
RA24: LINEAR
BA24: LINEAR
RG24: LINEAR
BG24: LINEAR
AR30: LINEAR
AB30: LINEAR
XR12: LINEAR
XB12: LINEAR
RX12: LINEAR
XR15: LINEAR
XB15: LINEAR
XR24: LINEAR
XB24: LINEAR
RX24: LINEAR
BX24: LINEAR
XR30: LINEAR
XB30: LINEAR
YUYV: LINEAR
UYVY: LINEAR
NV12: LINEAR
34 zpos:
flags: range
values: 0 1
value: 0
35 COLOR_ENCODING:
flags: enum
enums: ITU-R BT.601 YCbCr=0 ITU-R BT.709 YCbCr=1
value: 0
36 COLOR_RANGE:
flags: enum
enums: YCbCr limited range=0 YCbCr full range=1
value: 1
37 alpha:
flags: range
values: 0 65535
value: 65535
38 pixel blend mode:
flags: enum
enums: Pre-multiplied=0 Coverage=1
value: 0
42 0 0 0,0 0,0 0 0x00000001
formats: AR12 AB12 RA12 RG16 BG16 AR15 AB15 AR24 AB24 RA24 BA24 RG24 BG24 AR30 AB30 XR12 XB12 RX12 XR15 XB15 XR24 XB24 RX24 BX24 XR30 XB30 YUYV UYVY NV12
props:
8 type:
flags: immutable enum
enums: Overlay=0 Primary=1 Cursor=2
value: 0
30 IN_FORMATS:
flags: immutable blob
blobs:

value:
01000000000000001d00000018000000
01000000900000004152313241423132
52413132524731364247313641523135
41423135415232344142323452413234
42413234524732344247323441523330
41423330585231325842313252583132
58523135584231355852323458423234
52583234425832345852333058423330
59555956555956594e56313200000000
ffffff1f000000000000000000000000
0000000000000000
in_formats blob decoded:
AR12: LINEAR
AB12: LINEAR
RA12: LINEAR
RG16: LINEAR
BG16: LINEAR
AR15: LINEAR
AB15: LINEAR
AR24: LINEAR
AB24: LINEAR
RA24: LINEAR
BA24: LINEAR
RG24: LINEAR
BG24: LINEAR
AR30: LINEAR
AB30: LINEAR
XR12: LINEAR
XB12: LINEAR
RX12: LINEAR
XR15: LINEAR
XB15: LINEAR
XR24: LINEAR
XB24: LINEAR
RX24: LINEAR
BX24: LINEAR
XR30: LINEAR
XB30: LINEAR
YUYV: LINEAR
UYVY: LINEAR
NV12: LINEAR
44 zpos:
flags: range
values: 0 1
value: 1
45 COLOR_ENCODING:
flags: enum
enums: ITU-R BT.601 YCbCr=0 ITU-R BT.709 YCbCr=1
value: 0
46 COLOR_RANGE:
flags: enum
enums: YCbCr limited range=0 YCbCr full range=1
value: 1
47 alpha:
flags: range
values: 0 65535
value: 65535
48 pixel blend mode:
flags: enum
enums: Pre-multiplied=0 Coverage=1
value: 0

Frame buffers:
id size pitch

0 Takuma Fujiwara 4 months ago in reply to user5152479

TI__Guru 52873 points

Hi,

Those logs all look good. It seems software-wise, display driver is functional. We will now go through troubleshooting similar to what we did here: https://e2e.ti.com/support/amplifiers-group/amplifiers/f/amplifiers-forum/1456851/processor-sdk-am67-dts-configuration-for-dsi-convert-to-hdmi?pifragment-327888=1#5758752

So as a first question, have you physically measured the clock lines to see if clock is coming out of DSI?

Regards,

Takuma

0 Rich Chen 4 months ago in reply to Takuma Fujiwara

TI__Expert 4230 points

Takuma,

Yes, customer did measure the DSI clock line and see no clock output.

What troubleshoot do you mean, that e2e you pointed to is the case for same customer before changing DSI to HDMI bridge.

In the case, we can see DSI clock after setting overlay to Raspberry pi 7" panel.

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Without enable DT overlay, there is no DSI clock output.

After enable DT overlay to k3-am62p5-sk-dsi-rpi-7inch-panel.dtbo, customer see DSI clock output but there is no signal on data pairs.

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Does Lontium DRM driver set the device tree right to output DSI to Lontium bridge chip?

BR, Rich

0 Takuma Fujiwara 4 months ago in reply to Rich Chen

TI__Guru 52873 points

Hi Rich,

Troubleshooting by looking through different registers to see if there is an error reported in status registers.

Can you check if SoC is reporting errors by running "devmem2 0x305000F0", similar to other thread?

Regards,

Takuma

0 user5152479 4 months ago in reply to Takuma Fujiwara

Intellectual 525 points

Hi takuma,

when I setup modetest -M tidss -s 41@39:1920x1080-60 modetest -M tidss -s 41@39:800x600-60 , DSI data not output, but setup modetest -M tidss -s 41@39:640x480-66 , DSI havs data output, it seem that in the some config, DSI have data out, can you have some suggest?

0 Takuma Fujiwara 4 months ago in reply to user5152479

TI__Guru 52873 points

Hi,

Can you share the status register value for both the cases where DSI has data output and DSI has no data output? It should tell what is wrong.

Regards,

Takuma

0 user5152479 4 months ago in reply to Takuma Fujiwara

Intellectual 525 points

Hi, Takuma

what register to read?

0 Rich Chen 4 months ago in reply to user5152479

TI__Expert 4230 points

Takuma,

Could you specific what registers "status register value for both the cases" we can tell the output status?

BR, Rich

0 Takuma Fujiwara 4 months ago in reply to Rich Chen

TI__Guru 52873 points

Hi Rich and all,

Takuma Fujiwara said:
Can you check if SoC is reporting errors by running "devmem2 0x305000F0", similar to other thread?

Additionally, please reference other thread for register details: https://e2e.ti.com/support/amplifiers-group/amplifiers/f/amplifiers-forum/1456851/processor-sdk-am67-dts-configuration-for-dsi-convert-to-hdmi?pifragment-327888=1#5758752

Regards,

Takuma

0 user5152479 4 months ago in reply to Takuma Fujiwara

Intellectual 525 points

Hi Takuma.

0 Takuma Fujiwara 4 months ago in reply to user5152479

TI__Guru 52873 points

Hi,

Thanks for running the command. So, as expected, it looks like 640x480 the DSI register is reporting that it is running fine. However, 1920x1080 is reporting a ERR_MISSING_HSYNC.

Can you do a "modetest -M tidss" again, but run this when 640x480 resolution is used? The idea is to collect the timing parameter information that works, so that you can compare with the timing parameter used for 1920x1080.

Regards,

Takuma

0 Rich Chen 3 months ago in reply to Takuma Fujiwara

TI__Expert 4230 points

Takuma,

I do have question to confirm for status register which I am still confused on this status register.

How and why ERROR will be occur if this register is about DSI output?

DSI supports all output and with or without connected device behind should have not possible to feedback to DSI controller.

I look into TRM and I wonder if the status register error is about the signals from DPI interface to VSG with error but not actually the device behind DSI output?

BR, Rich

0 user5152479 3 months ago in reply to Rich Chen

Intellectual 525 points

//1920x1080：

root@ecu1270-b92682:~# modetest -M tidss
Encoders:
id crtc type possible crtcs possible clones
40 39 none 0x00000001 0x00000001

Connectors:
id encoder status name size (mm) modes encoders
41 40 connected HDMI-A-1 510x290 15 40
modes:
index name refresh (Hz) hdisp hss hse htot vdisp vss vse vtot
#0 1920x1080 60.00 1920 2008 2052 2200 1080 1084 1089 1125 148500 flags: phsync, pvsync; type: preferred, driver
#1 1680x1050 59.88 1680 1728 1760 1840 1050 1053 1059 1080 119000 flags: phsync, nvsync; type: driver
#2 1280x1024 75.02 1280 1296 1440 1688 1024 1025 1028 1066 135000 flags: phsync, pvsync; type: driver
#3 1280x1024 60.02 1280 1328 1440 1688 1024 1025 1028 1066 108000 flags: phsync, pvsync; type: driver
#4 1440x900 74.98 1440 1536 1688 1936 900 903 909 942 136750 flags: nhsync, pvsync; type: driver
#5 1440x900 59.90 1440 1488 1520 1600 900 903 909 926 88750 flags: phsync, nvsync; type: driver
#6 1280x720 60.00 1280 1390 1430 1650 720 725 730 750 74250 flags: phsync, pvsync; type: driver
#7 1024x768 75.03 1024 1040 1136 1312 768 769 772 800 78750 flags: phsync, pvsync; type: driver
#8 1024x768 60.00 1024 1048 1184 1344 768 771 777 806 65000 flags: nhsync, nvsync; type: driver
#9 800x600 75.00 800 816 896 1056 600 601 604 625 49500 flags: phsync, pvsync; type: driver
#10 800x600 60.32 800 840 968 1056 600 601 605 628 40000 flags: phsync, pvsync; type: driver
#11 640x480 75.00 640 656 720 840 480 481 484 500 31500 flags: nhsync, nvsync; type: driver
#12 640x480 72.81 640 664 704 832 480 489 492 520 31500 flags: nhsync, nvsync; type: driver
#13 640x480 66.67 640 704 768 864 480 483 486 525 30240 flags: nhsync, nvsync; type: driver
#14 720x400 70.08 720 738 846 900 400 412 414 449 28320 flags: nhsync, pvsync; type: driver
props:
1 EDID:
flags: immutable blob
blobs:

value:
00ffffffffffff00410c98c0333a0000
2619010380331d782a6e95a3544f9f26
115054bd4b00d1c08180950f9500b300
81c001010101023a801871382d40582c
4500fd1e1100001e000000ff00554842
31353338303134383939000000fc0050
68696c697073203233334534000000fd
00384c1e5311000a20202020202000f3
2 DPMS:
flags: enum
enums: On=0 Standby=1 Suspend=2 Off=3
value: 0
5 link-status:
flags: enum
enums: Good=0 Bad=1
value: 0
6 non-desktop:
flags: immutable range
values: 0 1
value: 0
4 TILE:
flags: immutable blob
blobs:

value:

CRTCs:
id fb pos size
39 50 (0,0) (1920x1080)
#0 1920x1080 60.00 1920 2008 2052 2200 1080 1084 1089 1125 148500 flags: phsync, pvsync; type: preferred, driver
props:
24 VRR_ENABLED:
flags: range
values: 0 1
value: 0
27 CTM:
flags: blob
blobs:

value:
28 GAMMA_LUT:
flags: blob
blobs:

value:
29 GAMMA_LUT_SIZE:
flags: immutable range
values: 0 4294967295
value: 256

value:
01000000000000001d00000018000000
01000000900000004152313241423132
52413132524731364247313641523135
41423135415232344142323452413234
42413234524732344247323441523330
41423330585231325842313252583132
58523135584231355852323458423234
52583234425832345852333058423330
59555956555956594e56313200000000
ffffff1f000000000000000000000000
0000000000000000
in_formats blob decoded:
AR12: LINEAR
AB12: LINEAR
RA12: LINEAR
RG16: LINEAR
BG16: LINEAR
AR15: LINEAR
AB15: LINEAR
AR24: LINEAR
AB24: LINEAR
RA24: LINEAR
BA24: LINEAR
RG24: LINEAR
BG24: LINEAR
AR30: LINEAR
AB30: LINEAR
XR12: LINEAR
XB12: LINEAR
RX12: LINEAR
XR15: LINEAR
XB15: LINEAR
XR24: LINEAR
XB24: LINEAR
RX24: LINEAR
BX24: LINEAR
XR30: LINEAR
XB30: LINEAR
YUYV: LINEAR
UYVY: LINEAR
NV12: LINEAR
44 zpos:
flags: range
values: 0 1
value: 1
45 COLOR_ENCODING:
flags: enum
enums: ITU-R BT.601 YCbCr=0 ITU-R BT.709 YCbCr=1
value: 0
46 COLOR_RANGE:
flags: enum
enums: YCbCr limited range=0 YCbCr full range=1
value: 1
47 alpha:
flags: range
values: 0 65535
value: 65535
48 pixel blend mode:
flags: enum
enums: Pre-multiplied=0 Coverage=1
value: 0

Frame buffers:
id size pitch

//640x480:

root@ecu1270-b92682:~# modetest -M tidss
Encoders:
id crtc type possible crtcs possible clones
40 39 none 0x00000001 0x00000001

value:

CRTCs:
id fb pos size
39 49 (0,0) (640x480)
#0 640x480 66.67 640 704 768 864 480 483 486 525 30240 flags: nhsync, nvsync; type: driver
props:
24 VRR_ENABLED:
flags: range
values: 0 1
value: 0
27 CTM:
flags: blob
blobs:

value:
28 GAMMA_LUT:
flags: blob
blobs:

value:
29 GAMMA_LUT_SIZE:
flags: immutable range
values: 0 4294967295
value: 256

Planes:
id crtc fb CRTC x,y x,y gamma size possible crtcs
32 39 49 0,0 0,0 0 0x00000001
formats: AR12 AB12 RA12 RG16 BG16 AR15 AB15 AR24 AB24 RA24 BA24 RG24 BG24 AR30 AB30 XR12 XB12 RX12 XR15 XB15 XR24 XB24 RX24 BX24 XR30 XB30 YUYV UYVY NV12
props:
8 type:
flags: immutable enum
enums: Overlay=0 Primary=1 Cursor=2
value: 1
30 IN_FORMATS:
flags: immutable blob
blobs:

value:
01000000000000001d00000018000000
01000000900000004152313241423132
52413132524731364247313641523135
41423135415232344142323452413234
42413234524732344247323441523330
41423330585231325842313252583132
58523135584231355852323458423234
52583234425832345852333058423330
59555956555956594e56313200000000
ffffff1f000000000000000000000000
0000000000000000
in_formats blob decoded:
AR12: LINEAR
AB12: LINEAR
RA12: LINEAR
RG16: LINEAR
BG16: LINEAR
AR15: LINEAR
AB15: LINEAR
AR24: LINEAR
AB24: LINEAR
RA24: LINEAR
BA24: LINEAR
RG24: LINEAR
BG24: LINEAR
AR30: LINEAR
AB30: LINEAR
XR12: LINEAR
XB12: LINEAR
RX12: LINEAR
XR15: LINEAR
XB15: LINEAR
XR24: LINEAR
XB24: LINEAR
RX24: LINEAR
BX24: LINEAR
XR30: LINEAR
XB30: LINEAR
YUYV: LINEAR
UYVY: LINEAR
NV12: LINEAR
44 zpos:
flags: range
values: 0 1
value: 1
45 COLOR_ENCODING:
flags: enum
enums: ITU-R BT.601 YCbCr=0 ITU-R BT.709 YCbCr=1
value: 0
46 COLOR_RANGE:
flags: enum
enums: YCbCr limited range=0 YCbCr full range=1
value: 1
47 alpha:
flags: range
values: 0 65535
value: 65535
48 pixel blend mode:
flags: enum
enums: Pre-multiplied=0 Coverage=1
value: 0

Frame buffers:
id size pitch

0 Takuma Fujiwara 3 months ago in reply to user5152479

TI__Guru 52873 points

Hi Rich,

Rich Chen said:
How and why ERROR will be occur if this register is about DSI output?

MIPI PHY itself has logic to report some error. Below is a screenshot from the "MIPI Alliance Specification for Display Serial Interface (DSI), v1.3.2" from the MIPI organization. Lane 0 can report back an error since it is a bidirectional signal during LP mode, which DSI can go into LP mode during blanking periods.

Bottom line is that DSI can report back error, and for more specific information, please read the specification.

Regards,

Takuma

0 Takuma Fujiwara 3 months ago in reply to Takuma Fujiwara

TI__Guru 52873 points

As for next experiments, could you try to select this mode line? Essentially, try testing any of the other negative sync mode lines.

#8 1024x768 60.00 1024 1048 1184 1344 768 771 777 806 65000 flags: nhsync, nvsync; type: driver

Please be aware that I see another 1024x768 that is using positive sync, so you would need to select the mode by index instead of resolution. Something like below:

modetest -M tidss -s 41@39:#8

Regards,

Takuma

0 user5152479 3 months ago in reply to Takuma Fujiwara

Intellectual 525 points

#8 1024x768 60.00 1024 1048 1184 1344 768 771 777 806 65000 flags: nhsync, nvsync; type: driver

this mode has clk and data outpu, status register is 0x1, but not display output.

0 Rich Chen 3 months ago in reply to user5152479

TI__Expert 4230 points

Takuma,

Lontium asks what our MIPI byteclk is?

Could you comment?

BR, Rich

0 Takuma Fujiwara 3 months ago in reply to Rich Chen

TI__Guru 52873 points

Hi Rich,

In DSI domain, we move from pixel clock to byte clock. We are using RGB888, which is 24 bits per pixel or 3 bytes.

So 65000kHz * 3 will be the byte clock for 1024x768. 31500kHz * 3 for 640x480.

Regards,

Takuma

0 Rich Chen 3 months ago in reply to Takuma Fujiwara

TI__Expert 4230 points

Takuma,

Thanks, I discussed with Lontium support team on the Hsync missing error reported on AM67x DSI status register, Lontium mentioned that there is MCU inside LT9611UXD and it can initial bridge itself.

Also, the data on Lane0 will be single direction on Lontium bridge and it is not bidirectional which means BTA (Bus Turn-Around) and BTR (Bus Turn-Around Read) is not supported.

LT9611UXD supports only video mode and it will not response to commend mode according to the discussion.

Therefore, Lontium suggest skipping initialization of LT9611UXD and turn off BTA then focus DSI output in video mode (1080p60 or 720P60).

Below are the timing which LT9611UXD firmware currently supported.

DSI 4 lanes and clock 1 lane, color format can be accommodate automatically.

Bases on such condition, could you provide a configuration to output 1080p60 as DSI video mode with the timing match to LT9611UXD can support?

We need first have LT9611UXD get input from AM67x to make sure connections.

BR, Rich

0 Takuma Fujiwara 3 months ago in reply to Rich Chen

TI__Guru 52873 points

Hi Rich,

Rich Chen said:
turn off BTA then focus DSI output in video mode

These should be configurable from Lontium's bridge driver using the DSI flags.

Rich Chen said:
Bases on such condition, could you provide a configuration to output 1080p60 as DSI video mode with the timing match to LT9611UXD can support?

As for timing parameters, these are auto-populated based off of connected HDMI display. You can force a specific timing parameter by deleting other possible timing parameters from the drm_edid.c. As an example that forces 640x480 at 60Hz, below is a hack that deletes all the other DMT modes within drm_edid.c:

https://e2e.ti.com/cfs-file/__key/communityserver-discussions-components-files/791/0007_2D00_drm_2D00_edid_2D00_Add_2D00_custom_2D00_DMT_2D00_modes.patch

You can define the timing parameters supported by the Lontium bridge and delete the other timings to experiment with the different parameters.

Regards,

Takuma

0 Rich Chen 3 months ago in reply to Takuma Fujiwara

TI__Expert 4230 points

Takuma,

The patch and hack provided for LT8912b looks different from current DRM driver so customer cannot find corresponding place to modify.

However, now we find only one setting #0x10 1024x768 60Hz can output successfully. (Status Register is 0x1)

modetest -M tidss -s 41@39:1024x768-60

All other resolution setting cannot output data (0nly clock, status Register is 0x4).

On Lontium debug console, it can detect 1024x768 input but the output cannot be locked so it cannot output to HDMI. We don't know exactly the reason why it cannot be locked.

Lontium asks to increase MIPI clock 10%, is this feasible?

For the patch 0001 you provide to change Postive Sync to Negative Sync, current LT9611 driver is different from LT8912b which we can not find corresponding place to modify or make similar change in DRM driver or Lontium driver.

Now our goal is to output 1920x1080p and status register can be 0x1 without error.

We have not identified the reason why Hsync error will occur but we have not change positive Sync to negative Sync. We will keep checking this in code.

BR, Rich

0 Takuma Fujiwara 3 months ago in reply to Rich Chen

TI__Guru 52873 points

Hi Rich,

The reason why 1024x768-60 worked is because it is using negative vsync and negative hsync. Below is from modeset output that customer had shared:

#8 1024x768 60.00 1024 1048 1184 1344 768 771 777 806 65000 flags: nhsync, nvsync; type: driver

Your customer has said 640x480 also worked, which is also negative vync and hsync.

Rich Chen said:
For the patch 0001 you provide to change Postive Sync to Negative Sync, current LT9611 driver is different from LT8912b which we can not find corresponding place to modify or make similar change in DRM driver or Lontium driver.

I would assume changes would be in lt9611uxc_video_setup. This is Lontium specific code to program the registers in the bridge hardware itself, so TI will not be able to help. But, the LT8912B driver can be used as reference.

Rich Chen said:
Now our goal is to output 1920x1080p and status register can be 0x1 without error.

Patch 7 will attempt to force 640x480 with negative vsync and negative hsync by deleting all other DMT modes. A similar thing can be done for 1920x1080 to output negative vsync and hsync.

Regards,

Takuma

0 Rich Chen 3 months ago in reply to Takuma Fujiwara

TI__Expert 4230 points

Takuma,

In Patch 7, it changes 800x600 and 1280x1024 from PHSYNC and PVSYNC to NHSYNC and NVSYNC.

However, patch 1 for LT8912b.c cannot be used directly to LT9611UXD since the driver LT9611UXD_main.C changes a lot so it cannot be hacked as this patch.

LT9611UXD driver is attached here. Could you check how to apply same change onto it?

0513.file.zip

Secondary, we were able to output 1024x768 or 800x600 (could depend on different HDMI monitor is used) onto LT9611UXD but it cannot be "locked" and send out HDMI display.

Lontium asked to increase MIPI clock by 10% as test.

You answered the MIPI clock rate is multiple pixel clock, how to change MIPI byte clock without change pixel clock?

Because changing pixel clock will change the FPS of output in same resolution, can we increase MIPI clock only by 10% in our DSI output? and where to modify?

"In DSI domain, we move from pixel clock to byte clock. We are using RGB888, which is 24 bits per pixel or 3 bytes. "

Please advise.

/* 0x04 - 640x480@60Hz */
{ DRM_MODE("640x480", DRM_MODE_TYPE_DRIVER, 25175, 640, 656,
752, 800, 0, 480, 490, 492, 525, 0,
DRM_MODE_FLAG_NHSYNC | DRM_MODE_FLAG_NVSYNC) },

/* 0x09 - 800x600@60Hz */
{ DRM_MODE("800x600", DRM_MODE_TYPE_DRIVER, 40000, 800, 840,
968, 1056, 0, 600, 601, 605, 628, 0,

+ DRM_MODE_FLAG_NHSYNC | DRM_MODE_FLAG_NVSYNC) },
{ DRM_MODE("1024x768", DRM_MODE_TYPE_DRIVER, 65000, 1024, 1048,
1184, 1344, 0, 768, 771, 777, 806, 0,
DRM_MODE_FLAG_NHSYNC | DRM_MODE_FLAG_NVSYNC) },
@@ -307,290 +253,13 @@ static const struct drm_display_mode drm_dmt_modes[] = {
{ DRM_MODE("1024x768", DRM_MODE_TYPE_DRIVER, 75000, 1024, 1048,
1184, 1328, 0, 768, 771, 777, 806, 0,
DRM_MODE_FLAG_NHSYNC | DRM_MODE_FLAG_NVSYNC) },

{ DRM_MODE("1280x1024", DRM_MODE_TYPE_DRIVER, 108000, 1280, 1328,
1440, 1688, 0, 1024, 1025, 1028, 1066, 0,

+ DRM_MODE_FLAG_NHSYNC | DRM_MODE_FLAG_NVSYNC) },
/* 0x52 - 1920x1080@60Hz */
{ DRM_MODE("1920x1080", DRM_MODE_TYPE_DRIVER, 148500, 1920, 2008,
2052, 2200, 0, 1080, 1084, 1089, 1125, 0,
DRM_MODE_FLAG_NHSYNC | DRM_MODE_FLAG_NVSYNC) },

BR, Rich

0 Takuma Fujiwara 3 months ago in reply to Rich Chen

TI__Guru 52873 points

Hi Rich,

Rich Chen said:
LT9611UXD driver is attached here. Could you check how to apply same change onto it?

Changes will be in lt9611ex_bridge_mode_set function. Specific change will be a register write to the lt9611ex bridge to set negative syncs. TI cannot help with creating the actual patch, because we do not have access to datasheet and inner workings of the lt9611ex bridge from Lontium to know which registers control the sync flags. Please have Lontium guide the customer to help.

Rich Chen said:
Because changing pixel clock will change the FPS of output in same resolution, can we increase MIPI clock only by 10% in our DSI output? and where to modify?

No, we do not recommend changing just the byte clock. In DSI driver, byte clock/bit clock (hs_clk_rate) is calculated from the pixel clock. My previous calculations may be slightly misleading if those are the cause of concern, because byte clock is a function of pixel clock, number of bits per pixel (bpp), and data lanes. The number of data lanes were not considered in my previous calculations I shared, so the calculation would be correct for a 1 lane DSI configuration.

In any case, you could try to experiment with cdns-dsi-core.c and the hs_clk_rate set in cdns_dsi_adjust_phy_configs, but I do not recommend changing around with the timings in this DSI driver since these timings are field tested and generally stable.

Regards,

Takuma

0 Rich Chen 3 months ago in reply to Takuma Fujiwara

TI__Expert 4230 points

Takuma,

We got no progress on modifying hs_clk_rate.

Currently, the implementation is try to add Lontium LT9611 as bridge and final output is HDMI.

EDID will be read and negotiate with controller to determine which resolution to output.

Now we would like to not consider bridge and force AM67x DSI output signals like to connect to a DSI panel.

First, we will disconnect LT9611 then try to output 1920x1080 60Hz video mode signals on DSI make sure we can sent out and see if it can be output directly without Lontium chip.

Then we will reconnect LT9611 to make sure whether connecting LT9611 will cause VSG stop.

We originally want to use Raspberry Pi 7" setting .dtso but found not sure how to set the resolution for panel.

Could you create a patch for panel mode and output 1920x1080 60Hz? Not to use bridge output. We want force DSI output directly without reading EDID and output HDMI.

Lontium bridge can convert to HDMI as long as DSI can send current signals to them.

BR, Rich

0 Takuma Fujiwara 3 months ago in reply to Rich Chen

TI__Guru 52873 points

Hi Rich,

I will work on a patch to see if I can output 1920x1080. However, this will take time.

In the meantime, please work with customer/Lontium to root cause why the 1024x768 resolution is not outputting to HDMI. SoC is outputting to bridge in 1024x768 case, so this can be used to unblock customer development team's debug.

Regards,

Takuma

Processors

Processors forum

AM67: AM67x work with DSI to HDMI bridge
