Got screen messed up while using DEI link for scaling

si NULL

Dear all:

We are using DM8168 and DVRRDK_04.00.00.03, and plan to use DEI link for scaling,

The following is my link chain:
Capture (YUV422I 1CH 2464*2048)
|
NSF (YUV420SP 1CH 2464*2048)
  |
DEI (YUV420SP 1CH 704*480)
  |
DUP
  |
|---------------|
| |
... IPC Frames Out1 (M3)
|
IPC Frames In0 (A8)
|
write to yuv file, then convert to jpg file

Out of NSF, VideoDataFormat is SYSTEM_DF_YUV420SP_UV, VideoScanFormat is SYSTEM_SF_PROGRESSIVE.

Below is my dei parameters:

DeiLink_CreateParams_Init(&deiPrm);
deiPrm.setVipScYuv422Format = FALSE;
deiPrm.inputDeiFrameRate = 30;
deiPrm.outputDeiFrameRate = 30;
deiPrm.enableDeiForceBypass = TRUE;
deiPrm.enableOut[DEI_LINK_OUT_QUE_VIP_SC] = TRUE;
deiPrm.tilerEnable[DEI_LINK_OUT_QUE_VIP_SC] = FALSE;
for(chId=0; chId<DEI_LINK_MAX_CH; chId++)
{
deiPrm.outScaleFactor[DEI_LINK_OUT_QUE_VIP_SC][chId].scaleMode = DEI_SCALE_MODE_ABSOLUTE;
deiPrm.outScaleFactor[DEI_LINK_OUT_QUE_VIP_SC][chId].absoluteResolution.outWidth = 704;
deiPrm.outScaleFactor[DEI_LINK_OUT_QUE_VIP_SC][chId].absoluteResolution.outHeight = 480;
}
deiPrm.inputFrameRate[DEI_LINK_OUT_QUE_VIP_SC] = 30;
deiPrm.outputFrameRate[DEI_LINK_OUT_QUE_VIP_SC] = 30;
deiPrm.numBufsPerCh[DEI_LINK_OUT_QUE_VIP_SC] = 4;
deiPrm.inQueParams.prevLinkId = nsfId;
deiPrm.inQueParams.prevLinkQueId = 0;
deiPrm.outQueParams[DEI_LINK_OUT_QUE_VIP_SC].nextLink = dupId;

When I run the system, I got screen messed up with no scaling, shows as the following jpg file:

If I remove DEI link, I got correct screen, shows as the following jpg file:

I also tried 1:1 scaling, that is, modify the followning two lines
deiPrm.outScaleFactor[DEI_LINK_OUT_QUE_VIP_SC][chId].absoluteResolution.outWidth = 704;
deiPrm.outScaleFactor[DEI_LINK_OUT_QUE_VIP_SC][chId].absoluteResolution.outHeight = 480;
to
deiPrm.outScaleFactor[DEI_LINK_OUT_QUE_VIP_SC][chId].absoluteResolution.outWidth = 2464;
deiPrm.outScaleFactor[DEI_LINK_OUT_QUE_VIP_SC][chId].absoluteResolution.outHeight = 2048;
and still got screen messed up, shows as the following jpg file:

How can I get correct scaling with DEI? Thanks!

over 11 years ago

0 Badri Narayanan over 11 years ago

TI__Guru 59700 points

Attach your usecase file and the app code which is writing the yuv to file. You are using wrong yuv format for writing or your pitch is wrong.

0 Badri Narayanan over 11 years ago in reply to Badri Narayanan

TI__Guru 59700 points

Also your input resolution is greater than 1920x1080.You will have to use MpSclr link to scale resolution greater than 1920x1080.

0 si NULL over 11 years ago in reply to Badri Narayanan

Prodigy 170 points

Hi, Badri !

Thanks for your so quick relay!

usecase file:

Fullscreen 7343.multich_vcap_venc_vdis.c Download

/*******************************************************************************
 *                                                                             *
 * Copyright (c) 2009 Texas Instruments Incorporated - http://www.ti.com/      *
 *                        ALL RIGHTS RESERVED                                  *
 *                                                                             *
 ******************************************************************************/

/*
                                           Capture (YUV422I 1CH 2464*2048)
                                               |
                                           NSF (YUV420SP 1CH 2464*2048)
                                               |
                                               |
                                              DEI (YUV420SP 1CH 704*480)
                                               |
                                              DUP
                                               |
                        -----------------------|--------------------------------------------------------------------------------------------------------
                        |                                                                                                                              |
                        |                                                                        NullSrc0          NullSrc1                            |
                   IPC Frames Out0 (M3)--<<process link>>--IPC Frames In(DSP)--ALGLINK          (2464*2048)       (2464*2048)*4                 IPC Frames Out1 (M3)
                        |                                                                             |                |                               |
                        ------------------------------------------------------------------------------|----------------|                        IPC Frames In0 (A8)
                        |                                                                                                                              |
                 Merge(ipcFrameout0, nullSrc0)                                                                                              write to yuv file (then manually convert to jpg file)
                        |
                     IPC OUT (M3)
                        |
                     IPC IN  (M3)
                        |
              Encode (1CH H264  + 1CH MJPEG  2448*2048)
                        |
                    IPC BITS OUT (M3)
                        |
                    IPC BITS IN  (A8)
*/
