PROCESSOR-SDK-DRA8X-TDA4X: ISX019 Sensor with GMSL1

Mahipal Reddy Patlolla

Part Number: PROCESSOR-SDK-DRA8X-TDA4X

Hi,

We have another camera with ISX019 sensor and GMSL1 SerDes. Out put fromat from the camera, as per the Manufacturer specification is YUV422 YCbCr.

TDAV4 is receiving the frames but when we look at the individual components of Y, U and V, Y is blank, Attached the corresponding png files.

Are there any restrictions on SoC side for YUV422 YCbCr format ? Do you have any suggestions on possible causes for this ?

over 6 years ago

0 Mahipal Reddy Patlolla over 6 years ago

Expert 2270 points

0 Mayank Mangla over 6 years ago

TI__Mastermind 24525 points

Hello Mahipal,

Visteon has been able to get YUV422 capture through IMX390 based sensor, so we can safely say that there is no SoC restriction. Can you please provide the original YUV frame as received (without PNG conversion)? Please let us know the width, height and bit-depth.

Regards,

Mayank

0 Mahipal Reddy Patlolla over 6 years ago in reply to Mayank Mangla

Expert 2270 points

isx019_Y_Blank.zip

0 Mahipal Reddy Patlolla over 6 years ago in reply to Mahipal Reddy Patlolla

Expert 2270 points

Hi Mayank,

PLease find attached teh details, we are configuring the driver and application with 1280*960 resolution. In IMX390 we didn't see the specification as YCbCr, it was mentioned as YUV422 8 Bit. That's why we need to know if the YCbCr in specific is making any difference. Attached all the YUV and png files.

Color Format (YUV, RGB, Raw, ….)	YUV422 YCbCr
Bit depth (e.g. 8,10,12 bit….)	8

Horizontal Total Resolution	1297
Horizontal Active Resolution	1280
Horizontal Front Porch	4clock
Horizontal Back Porch	722clock
Horizontal Sync Width	2560clock
Vertical Total Reolution	969
Vertical Active Resolution	960
Vertical Front Porch	1line
Vertical Back Porch	239line
Vertical Sync Width	3296clock
HSync Polarity	no
VSync Polarity	no
Frame Rate	25
Pixel Clock	99M

0 Mayank Mangla over 6 years ago in reply to Mahipal Reddy Patlolla

TI__Mastermind 24525 points

From data capture perspective YCbCr is same as YUV422. Can you use the same settings as IMX390 and share the captured YUV images?

0 Mayank Mangla over 6 years ago in reply to Mayank Mangla

TI__Mastermind 24525 points

Another comment ... Looking at frame_0000.u.png, it seemsthat there are 2 issues

1. The data you are getting is monochrome i.e. U and V are all zeros. Y pixels are correct.

2. The order of Luma and Chroma is swapped.

Please check with camera vendor if the data is expected to be monochrome.
